DEEPCOOL ASSASSIN VC ELITE Black Seven Heat Pipe, Dual-Tower Design Support Intel LGA 1851/ 1700 / 1200 / 1151 / 1150 / 1155, AMD AM5 / AM4

ASSASSIN VC ELITE - EMBRACE THE SUPREME

The ASSASSIN series adds to its impeccable cooling line with the ASSASSIN VC ELITE. With the new black-gold aesthetic, the ASSASSIN VC ELITE includes a vapor chamber at the base that improves heat transfer dramatically while increasing the TDP to 300 watts!

VAPOR CHAMBER-ENHANCED

Vapor chambers are essentially large, flattened heatpipes with high thermal conductance. In the ASSASSIN IV VC series, the heat is extracted through the coldplate, which starts the cooling process in the planar chamber. The heat gets equalized and sent up the heatpipes to get cooled further by the fin stacks. This solution raises the cooling capacity to an astounding 300W of TDP!

IN QUIET OR PERFORMANCE MODE

With a simple slide of a switch, the ASSASSIN VC ELITE can morph from a whisper-quiet cooler when low noise is of the utmost importance to the efficient cooling force DeepCool air coolers are known for.

ALL CLEAR!

The ASSASSIN VC ELITE's case is clean, sleek, and helps channel air through the fin towers, while the relocatable 120mm fan provides unobstructed clearance for high-profile RGB RAM.

RAM Clearance
Intel LGA1851/1700/1200/115X: Unobstructed
Intel LGA20XX: 63mm
AMD: AM4/AM5: Unobstructed

BE COOL, BE CALM

A key factor in the ASSASSIN VC ELITE's extremely silent operation is the use of three-phase, six-slot, four-pole fan motors with low voltage and power consumption. The high-end true FDB bearings in each of the fans are the gold standard, and for good reason.

120mm (Performance / Quiet):
500~1700 RPM±10% / 500-1350 RPM+10% Fan Speed
58.06 CFM / 46.75 CFM Fan Airflow
≤22.5 dB(A) / ≤19.9 dB(A) Fan Noise

140mm (Performance / Quiet):
500~1800 RPM±10% / 500~1450 RPM+10% Fan Speed
61.25 CFM / 48.55 CFM Fan Airflow
≤23.7 dB(A) / ≤20.5 dB(A) Fan Noise

EXCEPTIONAL BY DESIGN

Featuring a vapor chamber-enhanced base and seven heat pipes that deliver extremely efficient heat transfer through two fin-array heat sink towers for another level of high heat dissipation. The included DM9 thermal paste meets the rigorous standards used in industrial applications.

Vapor Chamber Enhanced Base

Elite-crafted nameplate

Elegant Black Cooler Shroud

Snap in relocatable 120mm fan frame (two height levels)

140mm True FDB Main Fan

120mm True FDB Rear Fan

Mode Selector

Dual Black Coated Fin Towers

Optional 3rd fan bracket included (multiple height adjustability)

Industrial grade thermal paste

THE FLOW BELOW

Due to the center 140mm fan sitting deep into the heart of the ASSASSIN VC ELITE, there is a lower flow of air that provides additional cooling to the toasty surrounding VRMs.

STREAMLINED INSTALLATION

Installing larger air coolers can be difficult and is a prime reason the hardware and installation was designed to be extremely user friendly. Even the magnetic top fan cover was crafted with ease of installation in mind.

WIDE RANGE OF MODERN CPU SOCKET COMPATIBILITY

The ASSASSIN VC ELITE supports virtually all modern mainstream CPU sockets from AMD and Intel, including the LGA1851 and AM5.

Intel: LGA1851/1700/1200/115X/20XX
AMD: AM5/AM4
