Transcend Embedded 64GB, M.2 2280 SSD, SATA3 B+M Key, MLC WD-15, Wide Temp
- Brand: Transcend Embedded
- MPN: TS64GMTS802I
- Part #: HDDTRSI11202

Product URL: https://www.pbtech.com/au/product/HDDTRSI11202/Transcend-Embedded-64GB-M2-2280-SSD-SATA3-BM-Key-M
Features
Transcend's MTS802M with SATA III 6Gb/s interface and ultra compact dimensions make it best suited to address the high-performance needs and strict size limitations of small form factor devices. This means it is perfect for use in today's modern ultrabooks, thin and light notebooks, and tablets. Built with the SATA III 6Gb/s specifications, and with a powerful controller and exceptional transfer speeds, the M.2 SSD easily handles everyday computing tasks as well as demanding multimedia applications.
Transcend also offers the MTS802I with wide temperature (-40? ~ 85?) capabilities to ensure sustained functionality, enhanced endurance and optimal reliability in mission-critical applications.
Firmware Features
- Built-in BCH ECC (Error Correction Code) functionality
- Advanced Global Wear-Leveling and Block management for reliability
- Advanced Garbage Collection
- Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
- TRIM command for better performance
- NCQ command for better performance
- Full drive encryption with Advanced Encryption Standard (AES) (optional)
- Power-saving DevSleep (Device Sleep) mode
Hardware Features
- Compliant with RoHS 2.0 standards
- Space-saving M.2 form factor (80mm) - ideal for mobile computing devices
- DDR3 DRAM Cache embedded
- MLC NAND flash
- Key components fortified by default with Corner Bond technology
- 30µ" PCB gold finger
- Anti-sulfur technology implemented to prevent sulfurization in the environment
- Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
- Promised operational reliability in a wide temperature range (from -40°C to 85°C)
- Supports Transcend Scope Pro software
Specifications
Appearance
Dimensions
80 mm x 22 mm x 3.58 mm (3.15" x 0.87" x 0.14")
Weight
9 g (0.32 oz)
M.2 Type
2280-D2-B-M (Double-sided)
Form Factor
M.2 2280
Interface
Bus Interface
SATA III 6Gb/s
Storage
Capacity
64 GB
Flash Type
MLC NAND flash
Operating Environment
Operating Voltage
3.3V±5%
Operating Temperature
Standard Temp.0°C (32°F) ~ 70°C (158°F)
Wide Temp.-40°C (-40°F) ~ 85°C (185°F)
Storage Temperature
-55°C (-67°F) ~ 85°C (185°F)
Humidity
5% ~ 95%
Shock
1500 G, 0.5 ms, 3 axis
Vibration (Operating)
20 G (peak-to-peak), 7 Hz ~ 2,000 Hz (frequency)
Power
Power Consumption (Operation)
2.64 watt(s)
Power Consumption (Sleep)
0.41 watt(s)
Performance
Sequential Read/Write (CrystalDiskMark)
Read: up to 530 MB/s
Write: up to 460 MB/s
4K Random Read/Write (IOmeter)
Read: up to 75,000 IOPS
Write: up to 75,000 IOPS
Mean Time Between Failures (MTBF)
2,500,000 hour(s)
Terabytes Written (TBW)
up to 2,360 TBW
Drive Writes Per Day (DWPD)
2.6 (3 yrs)
