Transcend Embedded 2TB, 2.5" SSD, SATA3, 3D TLC, PE: 3K, Wide Temp.
- Brand: Transcend Embedded
- MPN: TS2TSSD452K-I
- Part #: HDDTRSI20106

Product URL: https://www.pbtech.com/au/product/HDDTRSI20106/Transcend-Embedded-2TB-25-SSD-SATA3-3D-TLC-PE-3K-W
Features
Transcend's SSD452K features the SATA III 6Gb/s interface and state-of-the-art 3D NAND technology, which allows 96 layers of 3D NAND flash chips to be vertically stacked. Compared to 3D NAND at 64 layers, this density breakthrough greatly improves storage efficiency. The SSD452K is built with DRAM cache for fast access, and is fully tested in-house to guarantee reliability in mission-critical applications, boasting an endurance rating of 3K Program/Erase cycles.
Transcend also offers the SSD452K-I with wide temperature (-40? ~ 85?) capabilities to ensure sustained functionality, enhanced endurance and optimal reliability in mission-critical applications.
Firmware Features
- Dynamic thermal throttling
- -Built-in LDPC ECC (Error Correction Code) functionality
- Advanced Global Wear-Leveling and Block management for reliability
- Advanced Garbage Collection
- Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
- TRIM command for better performance
- NCQ command for better performance
- Full drive encryption with Advanced Encryption Standard (AES) (optional)
- Power-saving DevSleep (Device Sleep) mode (optional)
Hardware Features
- Compliant with RoHS 2.0 standards
- DDR3 DRAM Cache embedded
- Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
- Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
- Promised operational reliability in a wide temperature range (from -40°C to 85°C)
- Supports Transcend Scope Pro software
Specifications
Appearance
Dimensions
100 mm x 69.85 mm x 6.8 mm (3.94" x 2.75" x 0.27")
Weight
54 g (1.90 oz)
Form Factor
2.5"
Interface
Bus Interface
SATA III 6Gb/s
Storage
Capacity
2 TB
Flash Type
3D NAND flash
Operating Environment
Operating Voltage
5V±5%
Operating Temperature
Standard Temp.0°C (32°F) ~ 70°C (158°F)
Wide Temp.-40°C (-40°F) ~ 85°C (185°F)
Storage Temperature
-55°C (-67°F) ~ 85°C (185°F)
Humidity
5% ~ 95%
Shock
1500 G, 0.5 ms, 3 axis
Vibration (Operating)
20 G (peak-to-peak), 7 Hz ~ 2000 Hz (frequency)
Power
Power Consumption (Operation)
3.5 watt(s)
Power Consumption (Sleep)
0.5 watt(s)
Performance
Sequential Read/Write (CrystalDiskMark)
Read: up to 560 MB/s
Write: up to 520 MB/s
4K Random Read/Write (IOmeter)
Read: up to 90,000 IOPS
Write: up to 85,000 IOPS
Mean Time Between Failures (MTBF)
3,000,000 hour(s)
Terabytes Written (TBW)
up to 3,520 TBW
Drive Writes Per Day (DWPD)
1.61 (3 yrs)
