ADLINK STC-KL Series STC2-15WP-i7 4GB,64GB, Win10 IoT 15.6". PCAP touch, Kaby Lake M.2 SSD, IP65, VESA mount, 2x GbE LAN, RJ45, 2xCOM ports, 1xUSB 2.0, 1xUSB 3.0, 1x Mini PCIe card with PCIe and USB interface
- Brand: ADLINK
- MPN: 93-P2200-6C10
- Part #: IPCADL00137

Product URL: https://www.pbtech.com/au/product/IPCADL00137/ADLINK-STC-KL-Series-STC2-15WP-i7-4GB64GB-Win10-Io
Features
15.6" Smart Touch Computer, PCAP touch, 4GB, 64GB M.2 SSD
- Intel® Core™ i7-7600U
- 15.6" 16:9 LCD with LED backlight up to 50,000 hours
- Full HD (1920 x 1080) resolution
- 10-point PCAP touchscreen
- Anti-fingerprint surface treatment
Flexible configuration with advanced modularization
Manufacturers can easily customize the STC series industrial panel PCs for application-specific I/O and functionality, changing the level of computing performance, touch panel type, display size, and I/O interface. This customization accelerates development, verification, and validation, leading to saved time, money, and resources for any manufacturer.
Long-term durability and reliability
ADLINK's Standalone Panel PC (STC series) delivers a high ROI with its long-life support and outstanding reliability. Even in harsh environments with extreme temperatures or power input ranges, the STC series thrives thanks to their built-in overvoltage and undervoltage protection and their IP65-rated front panel.
Narrow bezel and slim design
The slim, lightweight frame allows for effortless integration and installation into any application, improving cost efficiency while looking stylish.
Plug in and ready to display anywhere
With support for Wall mount, VESA mount, and desktop stand, ADLINK's STC panel PCs offer an abundance of mounting options. They can even be embedded into control consoles for ultimate convenience.
Specifications
Model
STC2-15WP-KL
System
Processor
7th Gen Intel® Core™ Processor
Memory
4GB DDR3L
Storage
64GB SSD
Display
Size
15.6"
Resolution
1920 x 1080
Aspect Ratio
16:09
Brightness
400 nits (w/i touch)
Backlight Life (Hrs)
50,000
Viewing Angle (U/D/R/L)
89/89/89/89
Contrast Ratio
1000:1
Touchscreen
10-point, PCAP, Anti-fingerprint coating
I/O
Ethernet
2x GbE LAN, RJ-45
Serial Port
2x COM ports, RS-232/422/485
USB Port
1x USB 2.0, Type A
1x USB 3.0, Type A
Expansion
1x Mini PCIe card with PCIe and USB interface
Wi-Fi and Bluetooth
802.11 a/b/g/n/ac and Bluetooth 4.0 (Optional with Mini PCIe card)
Video
1x DP Port
Audio
1x audio port (line out)
Environmental
Operating Temperature
-10°C to 50°C (SSD)
Storage Temperature
-20°C to 60°C
Humidity
10% to 80% @ 40°C (non-condensing)
Vibration
Operating: 1G random 5 to 500Hz
Shock
Operating: 20G/11ms
IP Rating
Front IP65
Certifications & Compliance
CE/FCC
Power Input
9-36V DC input
OVP/UVP protection
Power Consumption
50.4W
Software
WDT
Watch Dog Timer supported
Operating System
Windows® 10 IoT Enterprise
Weight (Net/Gross)
3.4 kg /4.2 kg
Dimensions (H x W x D) (mm)
390x239x47
Mounting
VESA Mount, MIS-D 75mm x 75mm, 100mm x 100mm
