ADLINK Ind. Touch Panel OM-215H 21.5" Open frame, 1920x1080 16:9, FHD, PCAP, AF,1200nits (w/i touch), Wide temp., Front IP65
- Brand: ADLINK
- MPN: 93-P6000-B110
- Part #: IPCADLOM215002

Product URL: https://www.pbtech.com/au/product/IPCADLOM215002/ADLINK-Ind-Touch-Panel-OM-215H-215-Open-frame-1920
Features
21.5" Open Frame Industrial Touch Monitor (Widescreen with High Brightness)
- 21.5 (Widescreen) LCD panel with LED backlight with up to 50,000 service life
- 10-point PCAP touchscreen (glove-use available)
- Anti-fingerprint surface treatment for ease of cleaning and enhanced readability
- Wide viewing angles support both portrait and landscape modes
- IP 65 rating for water and dust protection
- Panel/ VESA/ Desktop Stand
High Durability
ADLINK team up with AUO® to ensure delivering the products with solid-build quality, which is protected with 7H hardness and an IP65 front panel. ADLINK's monitors can easily withstand the hazards of harsh environments, such as water, dust ingress, scratches, abrasions, and metallic dust. On average, these monitors have a mean time before failure (MTBF) of up to 50,000 hours, minimizing maintenance costs.
Smooth user interaction
ADLINK's projected capacitive technology supports 10-point multi-touch capabilities for smooth zoom, flick, rotate, swipe, drag, pinch, press, double tap, and other functions.
High readability
ADLINK's industrial touch screen monitors are optimized for outdoor or semi-outdoor use thanks to their high brightness and sunlight readability features. The screen surface is treated with an anti-fingerprint solution to facilitate cleaning and maximize readability, and with wide-viewing angles available, these monitors support both portrait and landscape orientations.
Immersive visuals
Easily adjust gamma correction, color saturation, brightness, contrast, and color balance with software programmable color management to reveal the true colors of stunning visuals.

Full Sizes, Slim Design, and Easy Mounting
The slim, light frame enables seamless integration and installation for any application. It also supports various mounting options from panel mount and VESA to desktop stand.
Specifications
Model
OM-215H
Display
Size
21.5"
Resolution (Max.)
1920 x 1080
Aspect Ratio
16:9
Color
16.7M
Brightness (w/ touch)
1200 nits
Backlight Life (Hrs)
50,000
Viewing Angle (U/D/R/L)
89/89/89/89
Contrast Ratio
3000:1
Touchscreen
10-point, PCAP, Anti-fingerprint coating
Bonding
Air bonding
I/O
USB Port
USB type B (for touch)
Video
HDMI x1, VGA x1
Audio
w/o Audio
Environmental
Operating Temperature
-20°C to 70°C
Storage Temperature
-20°C to 70°C
Humidity
10% to 80% @ 40°C (non-condensing)
Surface Hardness
7H
Vibration
Operating: 1G random 5 to 500Hz
Shock
Operating: 20G acceleration part to part, 11ms
IP Rating
Front IP65
Certifications & Compliance
CE/FCC
Power Input
DC-12V 5A Max.
Power Consumption
41.2 W
Mechanical
Net Weight/Gross Weight
5.1 kg /6.3 kg
Packing Dimensions (H x W x D mm)
640 x 480 x 160
Mounting
VESA Mount
VESA Mount (MIS-D 75mm x 75mm,100mm x 100mm) Panel, and Wall mount
