Advantech ADAM-6051 12DI/2Counter/2DO IoT Modbus/SNMP/MQTT Ethernet Remote I/O
- Brand: Advantech
- MPN: ADAM-6051-D
- Part #: IPCAVH010024

Product URL: https://www.pbtech.com/au/product/IPCAVH010024/Advantech-ADAM-6051-12DI2Counter2DO-IoT-ModbusSNMP
Features
ADAM-6000 accomplishes the integration of automation and enterprise systems easily through internet technology, so that users can avoid changing the entire architecture of the control system and even remotely monitor the device status more flexibly. ADAM-6000 modules are empowered by peer-to-peer (P2P) and Graphic Condition Logic (GCL), and can perform as standalone products for measurement, control and automation. Instead of having additional controllers or programming, system configurations can be done in an extremely short time with the easy-to-use and intuitive graphic utility.
- 12ch digital input/2ch counter/2ch digital output(pulse output)
- Protocols:MQTT(TLS),SNMP,Modbus TCP,RESTful API,ASCII
- GCL to perform basic logic control rules
- Peer-to-Peer function to map I/O status
- Cloud access: Data update to Azure
- Built-in web server
- Watchdog timer to recover the system
Specifications
Interface
Ethernet
Channels
14
Max. Input Frequency
4.5 kHz
Isolation Voltage
2,000 VDC
Operating Temperature
-40~70 °C (-40~158 °F)
Connectors
1 x RJ45, 1 x 13-pin plug-in screw terminal, 1 x 9-pin plug-in screw terminal
Protocol
Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command
Channels
12
Input Voltage
Dry Contact
Logic level 0: close to GND
Logic level 1: open
Wet Contact
Logic level 1: 10~30 VDC
Logic level 0: 0~3 VDC
Channels
2
Output Type
Sink
Output Voltage
0~30 VDC
Sink Current
100 mA max./channel
Input Voltage
10~30 VDC
