Advantech ARK-1551-S6A1 I5-8365UE 4COM 2GBE FANLESS

PB Tech price
PB Tech price
$ 2,028 .46
 +GST
$ 2,231 .31
 inc GST
$2,028.46  +GST
$2,231.31

Advantech ARK-1551-S6A1 I5-8365UE 4COM 2GBE FANLESS

  • Brand: Advantech
  • MPN: ARK-1551-S6A1
  • Part #: IPCAVH020002
  • UPC:
NEW ARRIVAL
PB Tech price
$ 2,028 .46 $ 2,231 .31
 +GST  inc GST
Hurry, only 1 unit left!


Delivery: Order now and it ships tomorrow
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$2,028.46  +GST
$2,231.31

Features

Intel® 8th Generation Core™ i5/Celeron Slim Fanless Computer

- Gen 8th Intel® Core™ i5/Celeron
- Dual DDR4 2400MHz SO-DIMM memory up to 32G
- 1 x swappable 2.5" SATA HDD drive bay and 1 x mSATA slot, supports Intel software RAID 0/1
- 4 x USB 3.1 Gen 2, 2 x Intel GbE LAN, 4 x RS-232/422/485, 8 bit GPIO
- 4K2K HDMI and VGA dual independent displays
- 1 x full-size mPCIe with SIM holder and 1 x M.2 2230 E Key
- Support Advantech SQF PCIex2 NVMe storage
- 12V - 24V @ -10%/+20% wide range power input
- RED for WiFi/BT/LTE are available

Specifications

CPU

Intel® Core™ i5-8365UE

Core Number

4

Frequency

1.6 GHz, turbo burst up to 4.1 GHz

BIOS

AMI EFI 256 Mbit

Technology

DDR4 2400MHz SO-DIMM

Max. Capacity

32 GB

Socket

2 x 260 pin SO-DIMM

ECC Support

No

Chipset

Intel UHD Graphics 620

Graphic Engine

Gen9 Low Power; 24 (UHD 620) /12(UHD 610) Execution Units. Media Codec Supported: H.264, MPEG2, MVC, VC-1, WMV9, H.265 / HEVC. 3D HW Acceleration: OpenGL 4.5, DirectX* 11.3/12, OpenCL* 2.1

HDMI

1

Dual Display

Yes, VGA + HDMI

Main System

Realtek ALC888S, High Definition Audio, Line-out, Mic-in

Controller

2

LAN1

10/100/1000 Mbps Intel i210 GbE, support Wake On Lan

LAN2

10/100/1000 Mbps Intel i219GbE, support Wake On LAN

Serial Port

4 x RS-232/422/485 support from 50 bps to 921.6 kbps, with auto flow control. COM3 with 5V/12V power, by jumper setting

Serial

4

USB Interface

4 x USB 3.1 Gen2, Type A connector

USB3.0

4

GPIO

8-bit

Mini PCI Express

1

Mini PCIe #1

1 x full-size mPCIe with 1x nano SIM holder (PCIe x2, USB 2.0x1, UIM, SATA x1)

M.2

1

Watchdog timer

255 levels timer interval, setup by software

TPM

Infineon SLB9665XQ 2.0

Case Open

Support

mSATA

1 x Full-size mSATA (*share with mPCIe slot)

PCIe

Support 2x Advantech SQF PCIex2 NVMe storage (1 x M.2 2230 E Key + 1 x mPCIe)

2.5" HDD/SSD

1 x Swappable 2.5" SATAIII drive bay (compatible with 7mm height

Microsoft Windows

Windows 10

Ubuntu

V

Power Type

AT/ATX

Input Voltage

12 ~ 24 VDC

Power Adaptor

AC to DC, 90W for 0 ~ 40 °C/ AC to DC, 120W for condition -20 ~ 55 °C (Optional)

Power Consumption

Typical 13.87 W, Max 47.12W

Manufacturer Part No:
ARK-1551-S6A1
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1.5 kg
PB Part No:
IPCAVH020002
Product Model:
ARK-1551-S6A1
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
