Advantech ADAM-5057S-AE 32-ch Isolated Digital Output Module
- Brand: Advantech
- MPN: ADAM-5057S-AE
- Part #: IPCAVH220125

Product URL: https://www.pbtech.com/au/product/IPCAVH220125/Advantech-ADAM-5057S-AE-32-ch-Isolated-Digital-Out
Features
ADAM-5057S
32-ch Isolated Digital Output Module
- Digital Output Channels:32
- Digital Output is Connect with ADAM-3920R
- 10A 250VDC&10A 30VDC Contact Rating
- 2500VDC optical isolation
- Only for ADAM-5560 series
Specifications
General
Certification
CE, FCC class A
Connectors
1 x 40 pin (wiring line)
Enclosure
ABS+PC
LED Indicator
On: Active
Off: Inactive
Power Consumption
1W (Max.)
Digital Output
Channels
32
Digital Output
Must connect with 2 units of ADAM-3920R
Protection
Optical Isolation
2,500 VDC
Overvoltage Protection
70 VDC
Relay Spec. of ADAM-3920R
Contact Rating
10A @ 250 VAC
10A @ 30 VDC
Contact Resistance
100 mO
Operation Time
15 ms
Relay Type SPST
(Form A)
Release Time
5 ms max
Life Expectancy
1.7 x 10^5 at related load
Insulation Resistance
1GO @ 500 VDC
Power Input
+24 VDC
Mounting
DIN 35 rail, wall, rack (with mounting kit)
Note
ADAM-5057S must connect with 2 units of ADAM-3920R via PCL-10220
Note
only for ADAM-5550 & 5560 Series
