Advantech BB-232OPDRI-PH ULI-232DE - RS-232 (DB9 Male / Female) Isolated Repeater
- Brand: Advantech
- MPN: BB-232OPDRI-PH
- Part #: IPCAVH220225

Product URL: https://www.pbtech.com/au/product/IPCAVH220225/Advantech-BB-232OPDRI-PH-ULI-232DE---RS-232-DB9-Ma
Features
ULI-232DE - Heavy Industrial RS-232 (DB9 Male / Female) Isolated Repeater
- Extends RS-232 data signals
- 2kV, three-way isolation (input/output/power)
- Data rate: 1.2 to 115.2 kbps
- Wide operating temperature: -40 to +85 °C
- Rugged IP30 metal case (panel or DIN rail mount)
- 10-48 Vdc input power (power supply required, sold separately)
- IEC-61850-3, IEEE-1613, NEMA TS2, FCC, CE, NEMA TS2, 50G Shock, 4G Vibration
Specifications
General
Technology
Serial
Mounting
Panel
Power
10-48VDC
Temperature
-40 to 85C
Isolation
2kV
Power and Data Isolated
Yes
Serial Type
RS-232
Serial Communication
Serial Standard
RS-232
Maximum Serial Transmission Speed
115.2 Kbps
Serial Port Connector Type
DB9
Serial Port Number
1
Repeater Maximum Distance
15 Meters
Environment
Operating Temperature
-40 ~ 85°C (-40 ~ 185°F)
Protection
ESD Protection
15 kV
Isolation
2,000 VDC
Certification
Safety
UL C1/D2 (Class I, Division 2)
Substation
IEC-61850-3
Power
Power Input (DC)
10 ~ 48 VDC
Accessory General
Mounting
Panel, DIN
Mechanism
Enclosure (Metal)
Metal
