Advantech IMC-370-MMST-PS-A Mini Media Converter,1000Mbps, Multimode 850nm, LFPT, 550m, ST, AC adapter
- Brand: Advantech
- MPN: IMC-370-MMST-PS-A
- Part #: IPCAVH220808

Product URL: https://www.pbtech.com/au/product/IPCAVH220808/Advantech-IMC-370-MMST-PS-A-Mini-Media-Converter10
Features
The IMC-370 series offers the most compact media converters. They can extend the 10, 100 and 1000Mbps twisted-pair network segments up to 80km over fiber technology. Supporting both 10/100/1000Mbps auto negotiation on the copper port and 1000Mbps full-duplex on the fiber port, the IMC-370 series serves as a media and data rate converter.
- Metal enclosure with compact size
- Industrial grade design that supports an extended operating temperature range
- Provides status LED
- Supports multiple power options: AC or DC adapter and dual USB cable
- Supports Link Fault Pass Through (LFPT)
- Centralized powered IMC-318I chassis
Specifications
MPN
IMC-370-MMST-PS-A
Also Known As
856-10730-ST-A
Optical Mode
Multi-Mode
Wavelength
850 nm
Distance
550 m
Optical Connector
ST
Technical
IEEE 802.3, 802.3u, 802.3ab, 802.3z
Supports jumbo frames up to 10240 bytes
Plug-and-play operation
Status LED
AutoCross for MDI/MDIX
Supports Link Fault Pass Through (LFPT)
Power Input
100 - 240V DC, 50-60Hz, 1.2A (IMC-370 AC input)
Environment
Operating Temperature
-25 to +70 °C (-13 to +158 °F)
Storage Temperature
-25 to +70 °C (-13 to +158 °F)
Operating Humidity
5 ~ 95% (non-condensing)
0 ~ 10,000 ft. altitude
Mechanical
Dimensions (H x W x D)
2.11 x 4.57 x 8.51 cm (0.83 x 1.80 x 3.35 in)
Weight
0.317 kg (0.7 lb)
Certifications
CE, FCC Class A, UL/cUL
