Advantech IMC-770-MM Managed Modular Media Converter,1000Mbps, Multimode 850nm, 550m, SC (also known as iMcV 856-11950)
- Brand: Advantech
- MPN: IMC-770-MM
- Part #: IPCAVH220928

Product URL: https://www.pbtech.com/au/product/IPCAVH220928/Advantech-IMC-770-MM-Managed-Modular-Media-Convert
Features
Managed Modular Media Converter,1000Mbps, Multimode 850nm, 550m, SC (also known as iMcV 856-11950)
- Variety of choices: multi-mode, single-mode or single-strand including SFP form factor
- The modular, hot-swappable architecture reduces operational costs associated with product installation, upgrades, and maintenance
- SNMP manageable
- Supports configuration control
- Supports Link Fault Pass Through (LFPT)
For more information: https://advdownload.advantech.com/productfile/PIS/IMC-770-MM/Product%20-%20Datasheet/IMC-770-MM20190424221410.pdf
Specifications
Ethernet Communication
Fiber Port Number
1
RJ-45 Port Number
1
Coaxial Port Number
0
Fiber Transmission Speed
10/100/1000 Mbps
Fiber Port Optical Mode
Multi-Mode
Fiber Transmission Wavelength
850 nm
Fiber Transmission Distance
550 m
Fiber Port Connector Type
SC Type
PoE Information
PoE Port Number
0
Mechanism
Number of Slot
0
Dimensions (W x H x D)
2.0 x 10.74 x 7.05 cm (0.78 x 4.19 x 2.75 in.)
Weight
0.11 kg (0.24 lbs)
Environment
Operating Temperature
0 ~ 50 °C (32 ~ 122°F)
Storage Temperature
-25 ~ 70°C (-13 ~ 158°F)
Operating Humidity
5~95% (non-condensing)
Certification
EMC
CE, FCC Class B
