Advantech PCI-1245E-AE Economic DSP-based 4-Axis Motion Control Universal PCI Card
- Brand: Advantech
- MPN: PCI-1245E-AE
- Part #: IPCAVH220960

Product URL: https://www.pbtech.com/au/product/IPCAVH220960/Advantech-PCI-1245E-AE-Economic-DSP-based-4-Axis-M
Features
- Encoder input is 10 MHz for 4xAB mode, 2.5 MHz for CW/CCW mode
- Pulse output up to 5 Mpps
- Memory buffer for trajectory planning (circular trajectory and auto blending are not supported)
- Supports E-Gear
- Hardware emergency input
- Watchdog timer
- Position latch via ORG & index signal
- Programmable interrupt
- RDY/LTC-dedicated input channels & SVON/CMP/CAM-DO/ERC-dedicated output channels are switchable for general input and output purposes
For more information: https://advdownload.advantech.com/productfile/PIS/PCI-1245E/file/PCI-1245E_1285E_DS(2024041520240415150348.pdf
Specifications
Pulse Type Motion Control
Motor Driver Support
Pulse-type servo/stepping
Number of Axis
PCI-1245E: 4
Interpolation
PCI-1245E: 2-axis linear
Max. Output Speed
5 Mbps
Step Count Range
±2, 147, 483, 646
Pulse Output Type
Pulse/direction (1-pulse, 1-direction type) or CW/CCW (2-pulse type)
Position Counters
Range of command and actual position
Velocity Profiles
T-Curve, S-Curve
Local I/O
Machine Interfaces: LMT+, LMT-, ORG
Servo Driver Interfaces: ALM, INP
General Digital I/O: PCI-1245E: 16-ch DI, 16-ch DO
Encoder Interface
Input Type Quadrature (A/B phase) or up/down
Counts per Enc. Cycle x1, x2, x4 (A/B phase only)
Input Range
PCI-1245E: 3~10V
Isolation Protection
2,500 VDC
Max. Input Frequency
10 MHz under 4xAB mode
General
Bus Type
Universal PCI V2.2
Connectors
PCI-1245E: 1 x 100-pin SCSI female connector
Dimensions (L x H)
175 x 100 mm (6.9" x 3.9")
Power Consumption
PCI-1245E: Typical: 5 V @ 850 mA
Max.: 5 V @ 1 A
Humidity
5 ~ 95% RH, non-condensing (IEC 60068-2-3)
Operating Temperature
0 ~ 60°C (32 ~ 140°F)
Storage Temperature
-20 ~ 85°C (-4 ~ 185°F)
