Advantech PPC-321W-PJ60A 21.5" FHD PPC w/Intel J6412, P-Cap
Advantech PPC-321W-PJ60A 21.5" FHD PPC w/Intel J6412, P-Cap
- Brand: Advantech
- MPN: PPC-321W-PJ60A
- Part #: IPCAVH221303
- UPC:
View all shipping info
- Brand: Advantech
- MPN: PPC-321W-PJ60A
- Part #: IPCAVH221303
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Industrial Automation & I/O





Advantech PPC-321W-PJ60A 21.5" FHD PPC w/Intel J6412, P-Cap
- Brand: Advantech
- MPN: PPC-321W-PJ60A
- Part #: IPCAVH221303

Product URL: https://www.pbtech.com/au/product/IPCAVH221303/Advantech-PPC-321W-PJ60A-215-FHD-PPC-wIntel-J6412
Features
PPC-321w EHL is an industrial panel PC with 21.5" FHD LCD, powered by Intel Celeron quad core J6412 processor. With aesthetic aluminum alloy enclosure, PPC-321w EHL ensures fanless reliability and easy maintenance in diverse industrial applications. Moreover, it provides more faster and flexible connection via 2 x 2.5G Ethernet port, 2 x USB 3.1 and 1 x Type C (USB only). The PPC-321w EHL is ideal for MES, processing and general industrial equipment integration.
- Industrial-grade 21.5" Full HD TFT LCD with 50K backlight lifetime
- Durable true-flat touchscreen with projected capacitive touch control
- Intel® Celeron® J6412 quad-core, 2.0 GHz, processor
- Up to 32 GB DDR4 SDRAM
- 1 x RS-232, 1 x RS-232/422/485, 2 x USB 2.0, and 2 x USB 3.1
- Compact, fanless design with solid aluminum alloy enclosure and IP66-rated front panel
- Supports E-key for wireless module
- Supports expansion via M.2 slot
- Supports Windows Embedded Linux and Android OS
For more information: https://advdownload.advantech.com/productfile/PIS/PPC-321W%20EHL/file/PPC-321W-EHL_DS(062024)20240621103730.pdf
Specifications
MPN
PPC-321W-PJ60A
21.5" PPC w/Intel J6412, P-Cap
Environment
Ingress Protection
Front Panel IP66
Operating Temperature
-10~50 °C (14~122 °F)
Relative Humidity
95% RH (non-condensing)
Storage Temperature
-20~60 °C (-4~140 °F)
Vibration Protection
2 Grms, random
Hardware
Certification
CE, FCC Class B, BSMI, CB, UL, CCC, UKCA
CPU
Intel® Celeron® J6412 2.00 GHz, Quad core
Ethernet
Intel® i225-LM
Expansion
1 x M.2 E Key 2230
I/O
1 x RS-232, 1 x RS-232/422/485, 2 x USB 3.0, 2 x USB 2.0, 1 x HDMI
LAN
2 x 10/100/1000/2500 Mbps
Memory
1 x DDR4 3200 MHz SDRAM Slot
OS Support
Microsoft® Windows 10 LTSC, Microsoft® Windows 11, Linux, Android
Power Consumption
50 W @ 19 VDC
Power Input
12~30 VDC
I/O Interface
Power Connector
1 x 2-Pin Terminal Block
Serial Ports
1 x RS-232, 1 x RS-232/422/485
LCD Display
Backlight Life (hrs)
50,000
Display Size
21.5"
Luminance (cd/m²)
250
Max. Resolution
1920 x 1080
Viewing Angle (H/V°)
178/178
Mechanical
Dimension (W x H x D)
558 x 350 x 61 mm
Enclosure
Die-cast aluminum alloy
Mounting
Stand, Wall, VESA, Panel
Weight (Net)
7.2 kg (15.9 lb)
Touchscreen
Touch Type
PCAP
USB Vision
Connector
2 x USB 3.0 Type A, 2 x USB 2.0 Type A
