Advantech PPC-419-RX6A 19" PPC w/Intel x6425E, Res.

PB Tech price
PB Tech price
$ 2,398 .13
 +GST
$ 2,637 .94
 inc GST
$2,398.13  +GST
$2,637.94

Advantech PPC-419-RX6A 19" PPC w/Intel x6425E, Res.

  • Brand: Advantech
  • MPN: PPC-419-RX6A
  • Part #: IPCAVH221317
  • UPC:
PB Tech price
$ 2,398 .13 $ 2,637 .94
 +GST  inc GST


Delivery: Order now and it ships on 25 Sep
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$2,398.13  +GST
$2,637.94

Features

19" Fanless Panel PC with Intel® Atom™ x6425E Processor

- 19" SXGA TFT LCD with resistive (default)or projected capacitive(by request) touchscreen
- Intel® Atom™ x6425E quad-core, 2.0 GHz processor
- Fanless, slim design
- Supports 1 x 2.5" SATA and 1 x M.2 B key slot for expansion
- 1 x PCI/PCIe x1 expansion slot
- Wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F)
- Wide range DC support (9 ~ 32 VDC)
- 1 x isolated RS-422/485 with automatic flow control
- Dual 2.5GBASE-T Ethernet supports Time-Sensitive Network(TSN) technology

Specifications

Hardware

CPU

Intel® Atom™ x6425E 2.0GHz Quad-Core

Memory

1 x DDR4 3200 MHz SDRAM Slot

Storage

1 x M.2 B key 2242/2280 (SATA/ USB3.0); 3042/3052 (5G), 1 x 2.5" SSD/HDD bay

LAN

2 x 10/100/1000/2500 Mbps

Ethernet

Intel® i226-LM

I/O

2 x RS-232, 1 x RS-422/485, 2 x USB 3.2, 2 x USB 2.0, 1 x Line Out, 1 x Mic In, 1 x HDMI, 1 x DP

Expansion

1 x M.2 E key 2230,1 x M.2 B key 2242/2280/3042/3052, 1 x PCIe x1 or 1 x PCI

Watchdog Timer

1~255 s

OS Support

Microsoft® Windows 10 LTSC, Microsoft® Windows 11, Linux

Power Input

9~32 VDC

Power Consumption

55 W @ 19 VDC

Certification

CE, FCC Class B, BSMI, CB, UL, CCC, UKCA

I/O Interface

Serial Ports

2 x RS-232, 1 x RS-232/422/485, 2 x RS-232 (Pin Header)

Audio

Line-Out, Mic-In

Displays

1 x HDMI, 1 x DP

Power Connector

1 x 2-Pin Terminal Block

USB Vision

Connector

2 x USB 3.2 Type A, 2 x USB 2.0 Type A

Mechanical

Dimension (W x H x D)

454 x 380 x 62 mm

Enclosure

Die-cast aluminum alloy, ABS

Mounting

Stand, Wall, VESA, Panel

Weight (Net)

7 kg (15.4 lb)

Touchscreen

Touch Type

5-wire resistive

LCD Display

Display Size

19"

Max. Resolution

1280 x 1024

Viewing Angle (H/V°)

170/160

Luminance (cd/m2)

350

Backlight Life (hrs)

50,000

Environment

Operating Temperature

-20~60 °C (-4~140 °F)

Storage Temperature

-40~60°C (-40~140°F)

Relative Humidity

95% RH (non-condensing)

Shock Protection

10 G, half sine

Vibration Protection

2 Grms, random

Ingress Protection

Front Panel IP66

Manufacturer Part No:
PPC-419-RX6A
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCAVH221317
Product Model:
PPC-419-RX6A
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
