Advantech TPC-107W-N31AB 7" WSVGA Touch Panel Computer with ARM Cortex -A53 Processor,Android 10
- Brand: Advantech
- MPN: TPC-107W-N31AB
- Part #: IPCAVH221337

Product URL: https://www.pbtech.com/au/product/IPCAVH221337/Advantech-TPC-107W-N31AB-7-WSVGA-Touch-Panel-Compu
Features
[Android] 7" Touch Panel Computer with ARM Cortex™-A53 Processor
- arm SystemReady IR certified
- NXP® ARM® Cortex™-A53 i.MX 8M Mini quad-core processor
- 7" 16:9 LCD with multi-touch P-CAP and true-flat IP66-rated front panel
- Up to 4 GB DDR4 RAM and 16 GB eMMC storage onboard
- 2 x 10/100/1000 Mbps LANs with optional IEEE 802.3at/af PoE-PD module support
- 1 mb FRAM backup memory for unexpected power interruptions
- 2 x Serial port with 120O termination resistor that one supports the CAN 2.0B protocol and offers a programmable bit rate of up to 1 Mb/sec
- Embedded browser and for rapid Web App development
- Supports Android
Specifications
LCD Display
Display Size
7"
Backlight Life (hrs)
50,000
Luminance
(cd/m2) 425
Max. Resolution
1024 x 600
Touchscreen
Touch Type
PCAP
Mechanical
Mounting
VESA, Panel
Environment
Relative Humidity
95% RH (non-condensing)
Hardware
CPU
NXP® ARM® Cortex™ A53 i.MX8M 1.6 GHz Quad-Core
Memory
1 x LPDDR4 with 2 GB
Storage
16 GB eMMC
LAN
10/100/1000Base-T Ethernet x 2
I/O
1 x RS-232, 1 x RS-232/422/485
Hardware Security
TPM 2.0
Certification
CB, UL, CE, FCC Class A, CCC, BSMI
OS Support
Android
Power Input
24 VDC ±20
Wireless Communication
Standard(Technology)
WIFI
Mechanical
Enclosure
Die cast magnesium alloy, Die-casting aluminum
Weight (Net)
2 kg (4.41 lb)
I/O Interface
USB Ports
2 x USB 2.0
