Advantech TPC-324W-P853B 23.8" widescreen PCT with Core i5 CPU and 8G RAM

PB Tech price
PB Tech price
$ 4,245 .77
 +GST
$ 4,670 .35
 inc GST
$4,245.77  +GST
$4,670.35

Advantech TPC-324W-P853B 23.8" widescreen PCT with Core i5 CPU and 8G RAM

  • Brand: Advantech
  • MPN: TPC-324W-P853B
  • Part #: IPCAVH221380
  • UPC:
PB Tech price
$ 4,245 .77 $ 4,670 .35
 +GST  inc GST


Delivery: Order now and it ships on 26 Sep
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$4,245.77  +GST
$4,670.35

Features

TPC-324W-P833B touch panel computer is equipped with TFT LCD, low-power 8th Gen. Intel® Core™ i5-8365UE Quad-core Processor , and built-in 8 GB DDR4 SO-DIMM delivering high performance yet compact and fanless computing system. To provide enhanced durability and satisfy diverse applications of industrial automation, TPC-324W-P853B features IP66-rated front panel protecting against dust and water ingress, and two extra expansion M.2 M Key, B Key slots supporting NVMe, SATA or 5G application. With Advantech's iDoor technology integrated via mini PCIe slot for function expansions such as additional I/O ports, isolated digital I/O, fieldbus protocols, GPS/GPRS/ Wi-Fi communication and MRAM. The integrated DP and audio ports allow a secondary monitor and speakers to be attached for increased functionality.

- 8th Gen. Intel® Core™ i5-8365UE Quad-core Processor with built-in 8 GB DDR4 SO-DIMM
- Dual channel memory slots support up to 64G in total
- Compact, fanless embedded system with aluminum alloy front bezel and chassis grounding protection
- True-flat touchscreen with 5-wire resistive touch control and IP66-rated front panel
- Support expansion via Full-size Mini PCIe and two M.2 slots (NVMe, 5G)
- Diverse system I/O and isolated digital I/O via iDoor technology
- Support fieldbus protocols/GPS/GPRS/Wi-Fi capabilities via iDoor technology
- Support TPM2.0 hardware security



For more information: https://advdownload.advantech.com/productfile/PIS/TPC-324W/file/TPC-312_315_317_324W_DS(020624)20240430102453.pdf

Specifications

General

BIOS

AMI UEFI

Certification

BSMI, CCC, CE, FCC Class A, CB/UL

Cooling System

Fanless design

Dimensions (W x H x D)

23.8": 595.9 x 374.1 x 70 mm (23.46 x 14.73 x 2.76 in)

Enclosure

Front bezel: Die cast aluminum alloy
Back housing: Die cast aluminum alloy

Mounting

VESA Mount, Desktop, Wall or Panel Mount

OS Support

Win 10, Android, Linux

Security

TPM 2.0 (built-in)

Power Consumption

23.8": 56.31W (Typical)

Power Input

24 VDC ± 20%

Watchdog Timer

15-255 sec (system)

Weight (Net)

23.8": 9.3kg (20.5lbs)

System Hardware

CPU

i5-8365UE 1.60 GHz Quad-core

Memory

Dual channel DDR4 SO-DIMM (Each channel supports up to 32G)
1 x 8G DDR4 SO-DIMM (Built-in)

LAN

2 x 10/100/1000BASE-T (A ver.) or 2.5GbE (B ver.)

Expansion Slot

1 x Full-size mini PCIe(PCIe/USB2.0)
1 x SIM (Optioanl 4G/5G module)

Storage Slot

1 x M.2 M key 2280 (SATA or NVMe PCIex4)
1 x M.2 B Key 2242 (SATA)
3042, 3052 (PCIe/USB3.0 for 4G/5G module)
1 x 2.5" SSD/ HDD (SATA, Max. 7mm)

I/O

2 x RS-232/422/485
1 x USB 2.0
4 x USB 3.2 (Gen 2)
1 x iDoor slot
1 x Displayport (Video output)
1 x Audio line out/ mic in

LCD Display

Display Type

FHD TFT LED

LCD Display Size

23.8" (16:9)

Max. Resoltuion

1920 x 1080

Max Colour

16.7M

Luminance (cd/m2)

350

Viewing Angle (H/V°)

178°/178°

Backlight Life

30,000hrs

Contrast Ratio

1000:1

Touchscreen

Lifespan

36 million touches at a single point

Light Transmission

Above 75%

Resolution

Linearity

Type

PCAP  (TPC-324W)

Environment

Relative Humidity

Operating, 95% RH @ 40° C, Non-Condensing,Non-Operating, 95% RH @ 60° C, Non-Condensing

Ingress Protection

IP66-rated front panel

Operating Temperature

-10~55°C (14~131°F) (w/o air flow)

Storage Temperature

-20~70°C (-4~158°F)

Vibration Protection

With SSD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)

Manufacturer Part No:
TPC-324W-P853B
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCAVH221380
Product Model:
TPC-324W-P853B
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
