Advantech FPM-D19T-CE 19" (5:4) SXGA (1280x1024) PCAP 350 nits modular front display design compatible with TPC-B610, TPC-B520, TPC-B300 models
- Brand: Advantech
- MPN: FPM-D19T-CE
- Part #: IPCAVH500004

Product URL: https://www.pbtech.com/au/product/IPCAVH500004/Advantech-FPM-D19T-CE-19-54-SXGA-1280x1024-PCAP-35
Features
19" (5:4) modular front display design compatible with TPC-B610, TPC-B520, TPC-B300 models
- 350 cd/m² luminance with 1280 x 1024 resolution
- High durability and performance with industrial-Grade LED LCD
- Advanced projected capacitive (P-CAP) technology
- IP66-rated front panel and panel mount support
- User-friendly system status LED indicators
Specifications
LCD Panel
Display Size
19"
Display Type
SXGA TFT LED LCD
Aspect Ratio
5:4
Max. Resolution
1280 x 1024
Max. Color
16.7M
Luminance
350 cd/m²
Viewing Angle (H/V)
170°/160°
Backlight Life
50,000 hr
Contrast Ratio
1000:1
Touchscreen
Type
PCAP
Light Transmission
Above 88%
Anti-Glare Treatment
Yes
Built-In iKey
N/A
Expandability
NFC Support on Front Panel
N/A
Environment
Operating Temperature
-20~60 °C (-4~140 °F)
Storage Temperature
-30~70 °C (-22~158 °F)
Ingress Protection
Font IP66
Housing Color
Panel Frame and Back Cover
Pantone 432C
