Advantech FPM-D15W-FHE 15.6" FHD (1920x1080) PCAP 1,200 nits High Brightness modular front display design compatible with TPC-B610, TPC-B520, TPC-B300 models
- Brand: Advantech
- MPN: FPM-D15W-FHE
- Part #: IPCAVH500010

Product URL: https://www.pbtech.com/au/product/IPCAVH500010/Advantech-FPM-D15W-FHE-156-FHD-1920x1080-PCAP-1200
Features
15.6" (FHD) High Brightness modular front display design compatible with TPC-B610, TPC-B520, TPC-B300 models
- Sunlight readable with 1200 cd/m² luminance with 1920 x 1080 (FHD) resolution
- High durability and performance with industrial-Grade LED LCD
- Advanced projected capacitive (P-CAP) technology
- IP66-rated front panel and panel mount support
- User-friendly system status LED indicators
Specifications
LCD Panel
Display Size
15.6"
Display Type
FHD TFT LED LCD
Aspect Ratio
16:9
Max. Resolution
1920 x 1080
Max. Color
16.7M
Luminance
1200 cd/m²
Viewing Angle (H/V)
178°/178°
Backlight Life
50,000 hr
Contrast Ratio
800:1
Touchscreen
Type
PCAP
Light Transmission
Above 88%
Anti-Glare Treatment
Yes
Built-In iKey
N/A
Expandability
NFC Support on Front Panel
N/A
Environment
Operating Temperature
-20~60 °C (-4~140 °F)
Storage Temperature
-30~70 °C (-22~158 °F)
Ingress Protection
Font IP66
Housing Color
Panel Frame and Back Cover
Pantone 432C
