JimiLab JM-VL01 4G LTE Vehicle GPS Tracker UMTS & GSM Network Support, ACC Detection for Ignition Status, Remote Cut-Off (Petrol/Power), WiFi Hotspot, Emergency SOS Button, RS485 Interface, with Lifetime LIC
- Brand: JimiLab
- MPN: JM-VL01
- Part #: IPCJIM0001

Product URL: https://www.pbtech.com/au/product/IPCJIM0001/JimiLab-JM-VL01-4G-LTE-Vehicle-GPS-Tracker-UMTS--G
Features
Improve the performance of your fleet business today with the feature-rich and lightning-fast JM-VL01. The JM-VL01 is a powerful and easy-to-install 4G GPS tracker that gives you actionable telematics insights. In addition to standard functions such as GPS location and geo-fence alerts, the JM-VL01 can also act as a WiFi hotspot.
Product is including the tracking platform of 10 years subscriptions. Contact [email protected], to register account for free softtware and APP.
Specifications
GNSS
Positioning system
GPS+WiFi
Frequency
L1
Positioning accuracy
<2.5m CEP
Tracking sensitivity
-162dBm
Acquisition sensitivity
-149dBm
TTFF (open sky)
Avg. hot start =1sec
Avg. cold start =45sec
Cellular
Communication network
LTE/UMTS/GSM
Frequency
JM-VL01LA:
LTE: B1/B2/B3/B4/B5/B7/B8/B28AB
UMTS/HSPA: 850/900/1900/2100 MHz
GSM: 850/900/1800/1900 MHz
JM-VL01A:
LTE: B2/B4/B5/B7/B12/B66
UMTS/HSPA: 850/1900 MHz
GSM: 850/1900 MHz
JM-VL01E:
LTE: B1/B3/B5/B7/B8/B20/B28A
UMTS/HSPA: 900/1900/2100MHz
GSM: 900/1800 MHz
Power
Battery
450mAh/3.7V industrial-grade Li-Polymer battery
Input voltage
9-36VDC
Interface
LED indication
GNSS (Blue), Cellular (Green), Power (Red)
SIM
Micro-SIM
Data storage
4Gb+2Gb
Digital inputs
ACC, SOS
Digital outputs
Relay
Physical specification
Dimensions
113.0 x 51.0 x 20.0mm
Weight
105g
Operating environment
Operating temperature
-20 to +70C
Operating humidity
5%~95%, non-condensing
IP rating
IP65
Feature
Sensors
Accelerometer
Scenarios
Vehicle movement alert, Over-speed alert, Geo-fence, Vehicle battery detection, Power supply disconnection
Driving behavior
analysis Harsh acceleration, Harsh braking, Harsh cornering, Collision
WiFi hotspot
2.4GHz
