JimiLab VL502 LTE OBDII GNSS Tracker, On board diagnostics, GPS & BDS positioning, collision alarm, multiple alert INS-aided GPS tracking, driving behaviour analysis, mileage accuracy >98%, effortless installation

PB Tech price
PB Tech price
$ 126 .92
 +GST
$ 139 .61
 inc GST
$126.92  +GST
$139.61

JimiLab VL502 LTE OBDII GNSS Tracker, On board diagnostics, GPS & BDS positioning, collision alarm, multiple alert INS-aided GPS tracking, driving behaviour analysis, mileage accuracy >98%, effortless installation

  • Brand: JimiLab
  • MPN: VL502
  • Part #: IPCJIM0005
  • UPC:
PB Tech price
$ 126 .92 $ 139 .61
 +GST  inc GST


Delivery: Order now and it ships today
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$126.92  +GST
$139.61

Features

The VL502 is a new generation of 4G Cat 1 OBD II tracker for corporate cars, usage-based insurance, fleet management, and individual cars, which can obtain vehicle data such as VIN code, engine speed, water temperature, accumulated mileage, etc. With the UBI-based algorithm for driving behavior analysis, the VL502 can accurately analyze any of 4 kinds of dangerous driving behavior and support the all-round monitoring of vehicles' real-time status.

Product is including the tracking platform of 10 years subscriptions. Contact [email protected], to register account for free softtware and APP.

;

;

Specifications

GNSS

Positioning system

GPS/BDS

Frequency

L1

Positioning accuracy

<2.5m CEP

Track sensitivity

-162 dBm

Acquisition sensitivity

-148 dBm (cold) /-156 dBM (hot)

TTFF (open sky)

Avg. hot start =1sec
Avg. cold start =32sec

Cellular

Communication network

LTE + GSM

Frequency

VL502 (L):
LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66
GSM: B2/B3/B5/B8

VL502 (E):
LTE-FDD: B1/B3/B5/B7/B8/B20/B28
GSM: B2/B3/B5/B8

Power

Battery

50mAh/3.7V

Input voltage

9-36VDC

Interface

LED indication

1 status indicator (Blue)

SIM

Nano-SIM

Data storage

8+16MB

OBD port

Connection

OBD II

Data

K-Line, CAN Bus

OBD protocols

ISO 9141-2 (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (fast init, 10.4 kbaud)
ISO 15765-4 CAN (11 bit ID, 250 kbaud)
ISO 15765-4 CAN (11 bit ID, 500 kbaud)
ISO 15765-4 CAN (29 bit ID, 250 kbaud)
ISO 15765-4 CAN (29 bit ID, 500 kbaud)
SAE J1939 CAN(29bit ID, 250kbaud)
SAE J1939 CAN(29bit ID, 500kbaud)

Physical specification

Dimensions

61.0 x 52.0 x 26.0mm

Weight

55g

Operating environment

Operating temperature

-20°C to 70°C

Operating humidity

5%~95%, non-condensing

General

Sensors

Accelerometer

Ignition detection

External Power Voltage

Scenarios

Car Fault, Over-Speed, Ignition detection, Collision, Geo-fence entry/exit, Power on, Device pull-out, Engine idling

Driving behavior analysis

Harsh acceleration, Harsh braking, Harsh cornering, Collision

Note

* We reserve the right of final interpretation of this page. All information is for reference only and is subject to change without further notice.

Manufacturer Part No:
VL502
Brand:
JimiLab
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.2 kg
PB Part No:
IPCJIM0005
Product Model:
VL502
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
