Fanvil i63 Video Door Phone 2 Mega-pixel camera - SIP - ONVIF - IP66 - IK07 - Aluminum Alloy Design
- Brand: Fanvil
- MPN: FAN-i63
- Part #: IPHFAN1078

Product URL: https://www.pbtech.com/au/product/IPHFAN1078/Fanvil-i63-Video-Door-Phone-2-Mega-pixel-camera
Features
Based on SIP and ONVIF protocols, i63 is a video door phone that integrates powerful functionalities of access control, intercom, and security protection. Featuring an aluminum alloy design and 5 speed-dial buttons, i63 delivers a high-quality elegant appearance. With high protection level IP66 and IK07, it is waterproof, dustproof and anti-collision in most outdoor environments. i63 allows users to make audio/video calls via a speed-dial button and a 2 Mega-pixel camera and achieve access control by different modes. With rich input and output interfaces, i63 is easy to link with other security devices and customize into various solutions in apartments, commercial buildings, communities and industrial parks.
- High protection level of IP66 and IK07, wide temperature range from -40°C to 70°C
- Support to open door with RFID/IC cards, indoor switch, remote DTMF and Timed open door
- Aluminum alloy design and 5 speed-dial touch buttons
- Built-in 2 Mega-pixel wide-angle camera: 120°(H), 60°(V) with infrared night-vision feature
- Compatible with ONVIF protocol
- Built-in 3 short-in detect ports and 2 short-out control ports, can be integrated with induction loop antenna
- Built-in maximum 128GB capacity TF card slot for image storage
- HD voice speech quality with built-in 2.5W speaker and Acoustic Echo Canceller
Specifications
Size
177.4x88x36.15mm
Speed-dial Button
Five speed dial touch buttons
Numerical Keypad
No
SIP Lines
2
Access Card Number
10000
Ways to Unlock Door
DTMF, RFID/IC Card, Indoor Switch, Timed open door
Tamper-Proof
Yes
Wideband Codec
G722/Opus
Narrowband Codec
G711A/U,G729A/B, iLBC,G723.1, G.726-32K
Camera
2 Mega-pixel
Motion Detection
Yes
Supplement Light
IR Supplement
Power Amplifier ONVIF
2.5W
ONVIF
Yes
TF Card
Up to 128G
Line-out Interface
Yes
Short Circuit Output
2
Short Circuit Input
3
Door Magnetic Port
Yes
Wiegand Port
Yes
Flush-mounted
Yes
Wall-mounted
Yes
Protection Level
IP66, IK07
Temperature Range
-40°C~+70°C
