EV Peak EV-CD1XR AC/DC DUO 1-6S LiXX 1-15S NiXX 100Wx2 10A
Out of stock
EV Peak EV-CD1XR AC/DC DUO 1-6S LiXX 1-15S NiXX 100Wx2 10A
- Brand: EV Peak
- MPN: EV-Peak EV-CD1XR
- Part #: MDLEVPV-CD1XR
- UPC:
View all shipping info
- Brand: EV Peak
- MPN: EV-Peak EV-CD1XR
- Part #: MDLEVPV-CD1XR
- UPC:
Features
Like the "carbon" element is the fundamental component of life, C Series charger are the first round intelligent balance chargers which are designed for worldwide RC hobby users, and form the basis of the following balance chargers of EV-PEAK. This charger adopts the 32-bit MCU instead of commonly found 8-bit MCU, making operation faster and much more accurate.
CD1-XR charger is an AC/DC DUO balance charger/discharger,it supports 1-6 cells LiPo/LiHV/LiFe batteries and 1-15 cells NiMH/NiCd batteries,maximum 10A charge per channel.
- Powerful Dual 100W charging circuits.
- 20 Battery memory profiles
- Powerful 32 Bit CPU Core
- AC/DC Dual Input
- LiPo/LiHV/LiFE/NiMH/NiCD/PB Battery support
- Built in Balancing circuit.
- Two High speed cooling regulated cooling fans.
- High Power Discharge circuit.
- PC Communication available via USB.
LiHV Battery Support
This high-end charger supports the new LiHV chemistry battery! Charge, discharge and storage charge your LiHV's
Convenience
Charge two batteries at once. Even if they are not the same chemistry, voltage, or capacity. This charger has 2 individual charge ports and plugs directly into the wall. It also can be connected to a DC power source such as a 12V car battery or a DC Power Supply.
The Charger also features LiPo Balance Charge, LiPo Storage, and LiPo Discharge modes.
Reliability
EV-Peak is known for their great reliability. They use the best internal components and circuitry available to create long lasting products. Their reliability rivals that of name brand manufacturers such as Hitec, Duratrax, Traxxas, etc.
High Power Output
This charger boasts 100Watts of power per port! Most chargers such as Duratrax only offer 40Watts per channel. Some may even offer 50Watts. But this charger leaves them all in the dust, allowing your packs to charge faster! It offers a 10Amp charge rate.
Digital Power Mode
Each Port can act as a power supply! Use this function to power external items such as a pit light, tire truer, motor checker, charger, or anything else that runs off of DC power. Both the Voltage and Amperage are adjustable to suit the needs of the connected device.
Lithium Cell Check
Check the voltage of a Lithium battery's cells when plugged into the balance port. Simply hold the INC button when in a Lithium menu. The screen will provide a readout of each cell?s voltage.
Adjustable Cutoff Voltage
The voltage per cell at which the charger stops charging the battery can be adjusted for fine user precision. Adjustments available for LiPo, LiHV, LiIo, LiFe, Pb batteries. (Adjustment values listed below)
Specifications
Reviews
Delivery & Pick-up
.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security and Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
Delivery Estimates
The delivery time-frame (in days) for each product we sell is detailed on the individual product page just to the right of the main product image. From when you place your order, for DHL express delivery in-stock products typically arrive within 2-3 working days for metro areas and 3-5 working days for rural areas. For Standard delivery in-stock products typically arrive within 3-7 working days for NSW, VIC, ACT, QLD and SA deliveries and 5-10 working days for WA, TAS and NT.
Overseas Shipments
If you are located in New Zealand, you can order directly from our New Zealand site www.pbtech.co.nz. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Other Plastic Model Kits
Tamiya 95676 Mini 4WD Cyclone Magnum PC-SP AR FC30
Tamiya 95142 Jr Hyper Dash Motor Pro J-Cup 2021
Tamiya 95623 Mini 4WD Super Emperor SP Kit
Italeri 1-6195 1/72 Battle for the Reichstag 1945 - BATTLE SET
Tamiya 15534 MINI 4WD SDLP TYRE 26 CHROME FIN WHEEL
EV Peak EV-CD1XR AC/DC DUO 1-6S LiXX 1-15S NiXX 100Wx2 10A
- Brand: EV Peak
- MPN: EV-Peak EV-CD1XR
- Part #: MDLEVPV-CD1XR
Product URL: https://www.pbtech.com/au/product/MDLEVPV-CD1XR/EV-Peak-EV-CD1XR-ACDC-DUO-1-6S-LiXX-1-15S-NiXX-100
Features
Like the "carbon" element is the fundamental component of life, C Series charger are the first round intelligent balance chargers which are designed for worldwide RC hobby users, and form the basis of the following balance chargers of EV-PEAK. This charger adopts the 32-bit MCU instead of commonly found 8-bit MCU, making operation faster and much more accurate.
CD1-XR charger is an AC/DC DUO balance charger/discharger,it supports 1-6 cells LiPo/LiHV/LiFe batteries and 1-15 cells NiMH/NiCd batteries,maximum 10A charge per channel.
- Powerful Dual 100W charging circuits.
- 20 Battery memory profiles
- Powerful 32 Bit CPU Core
- AC/DC Dual Input
- LiPo/LiHV/LiFE/NiMH/NiCD/PB Battery support
- Built in Balancing circuit.
- Two High speed cooling regulated cooling fans.
- High Power Discharge circuit.
- PC Communication available via USB.
LiHV Battery Support
This high-end charger supports the new LiHV chemistry battery! Charge, discharge and storage charge your LiHV's
Convenience
Charge two batteries at once. Even if they are not the same chemistry, voltage, or capacity. This charger has 2 individual charge ports and plugs directly into the wall. It also can be connected to a DC power source such as a 12V car battery or a DC Power Supply.
The Charger also features LiPo Balance Charge, LiPo Storage, and LiPo Discharge modes.
Reliability
EV-Peak is known for their great reliability. They use the best internal components and circuitry available to create long lasting products. Their reliability rivals that of name brand manufacturers such as Hitec, Duratrax, Traxxas, etc.
High Power Output
This charger boasts 100Watts of power per port! Most chargers such as Duratrax only offer 40Watts per channel. Some may even offer 50Watts. But this charger leaves them all in the dust, allowing your packs to charge faster! It offers a 10Amp charge rate.
Digital Power Mode
Each Port can act as a power supply! Use this function to power external items such as a pit light, tire truer, motor checker, charger, or anything else that runs off of DC power. Both the Voltage and Amperage are adjustable to suit the needs of the connected device.
Lithium Cell Check
Check the voltage of a Lithium battery's cells when plugged into the balance port. Simply hold the INC button when in a Lithium menu. The screen will provide a readout of each cell?s voltage.
Adjustable Cutoff Voltage
The voltage per cell at which the charger stops charging the battery can be adjusted for fine user precision. Adjustments available for LiPo, LiHV, LiIo, LiFe, Pb batteries. (Adjustment values listed below)
Specifications
AC Input voltage
AC 100V-120V OR 220V-240V (selectable via switch)
DC Input voltage
DC 11.0V-18.0V
Charge current
0.1A-10.0A*
Discharge current
0.1A-5.0A*
Charge power
max.100W x 2
Discharge power
max. 20W x 2
Balance current
max. 400mA
Balance tolerance
±0.01V
NiCd/NiMH battery cell count
1-16cells
Lithium battery types
Li-Po, Li-HV, Li-ion, Li-Fe
Lithium battery cell count
1-6series
Pb battery voltage
2V-24V
mAh Capacity
100mAh - 25,000mAh (Can charge batteries w/ higher capacity, but restarting the charge process will be required once maximum is reached)
Digital Power
3V-24V
Dimensions
204 x 170 x 60mm
Note
Charger has 10A/100W limit per port, whichever is reached first. Charger will auto-adjust the amperage if the max wattage is reached. For example, charging a 4S LiPo: 100Watts / 14.8Volts = approx. 6.7Amp max charge rate.
