TP-Link Omada DR3650v-4G 4G+ CAT6 Gigabit Multi-WAN VPN ADSL/VDSL Gateway with Dual-Band WiFi 6 AX3000
1GbE x5 / Nano-SIM Slot x2
TP-Link Omada DR3650v-4G 4G+ CAT6 Gigabit Multi-WAN VPN ADSL/VDSL Gateway with Dual-Band WiFi 6 AX3000
1GbE x5 / Nano-SIM Slot x2
- Brand: TP-Link
- MPN: DR3650v-4G
- Part #: MODTPL3650
- UPC:
View all shipping info
- Brand: TP-Link
- MPN: DR3650v-4G
- Part #: MODTPL3650
- UPC:
Features
DR3650v-4G
Omada 4G+ Cat6 AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway
- AX3000 WiFi 6 with 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz*1
- 4G+ Cat6 up to 300Mbps
- 3x RJ11 Ports (2x FXS, 1x DSL) & 5x RJ45 Gigabit Ports & 1x USB 3.0 Port
- 2x Nano SIM for 4G/LTE Failover
- VDSL2 35b: Supports 350Mbps DSL Access*2
- VDSL2/ADSL2+/ADSL2/ADSL Compatibility
- IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL VPN
- Load Balancing Across DSL, 4G, and Ethernet WAN for Optimized Connectivity
- Centralized Cloud Management
- Desktop/Wall/Rack Mounting (Purchase Rackmount Kit-D226 Separately)
Get the Higher DSL Speeds Cost-Effectively
The integrated DSL port supports VDSL2/ADSL2+/ADSL2/ADSL connections. Compatibility with the leading ISPs provides ideal IP-based connections for any small business.
Get Instant 4G+ LTE - Internet up to 300 Mbps
Versatile Connectivity
DR3650v-4G's compatible with Super VDSL (VDSL2 Profile 35b), Ethernet access, and 4G/3G USB modems. Its Gigabit LAN/WAN port accepts connections from cable or fiber modems, and the FXS ports supports VoIP for reliable voice communication. The USB 3.0 port supports 4G/3G dongles for a solid main or backup internet connection.
Up to 3.0 Gbps Business-Level Wi-Fi 6 Empowers Small and Medium Business*
HE 160
Double the data at peak transmission times on a single stream
OFDMA
Enables different devices to share one transmission stream, increasing efficiency
1024 QAM
25% more data encoded at one time
Software Defined Networking (SDN) with Cloud Access
Centralised cloud management for Omada gateways, switches, and access points across multiple sites, with the Omada cloud-based controller offering the Essentials version of cloud services for free, reducing maintaince costs.
High-Security and High-Performance VPN
SSL/ IPSec / GRE / WireGuard / PPTP / L2TP VPN & OpenVPN easily build secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study from home.
In the Box
Build Features
Specifications
Reviews
Delivery & Pick-up
.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security and Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
Delivery Estimates
The delivery time-frame (in days) for each product we sell is detailed on the individual product page just to the right of the main product image. From when you place your order, for DHL express delivery in-stock products typically arrive within 2-3 working days for metro areas and 3-5 working days for rural areas. For Standard delivery in-stock products typically arrive within 3-7 working days for NSW, VIC, ACT, QLD and SA deliveries and 5-10 working days for WA, TAS and NT.
Overseas Shipments
If you are located in New Zealand, you can order directly from our New Zealand site www.pbtech.co.nz. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Modems
TP-Link Archer VX1800v AX1800 Dual-Band WiFi 6 VDSL / ADSL Modem...
FRITZ!Box 7530AX WiFi 6 (802.11ax) ADSL / VDSL / UFB Router GigE...
TP-Link Archer VR2100 ADSL / VDSL AC2100 Dual-Band WiFi 5 Modem...
TP-Link Deco X50-DSL ADSL / VDSL AX3000 Dual-Band WiFi 6 Whole...
TP-Link Deco X50-DSL ADSL / VDSL AX3000 Dual-Band WiFi 6 Whole...
TP-Link Omada DR3650v-4G 4G+ CAT6 Gigabit Multi-WAN VPN ADSL/VDSL Gateway with Dual-Band WiFi 6 AX3000 1GbE x5 / Nano-SIM Slot x2
- Brand: TP-Link
- MPN: DR3650v-4G
- Part #: MODTPL3650
Product URL: https://www.pbtech.com/au/product/MODTPL3650/TP-Link-Omada-DR3650v-4G-4G-CAT6-Gigabit-Multi-WAN
Features
DR3650v-4G
Omada 4G+ Cat6 AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway
- AX3000 WiFi 6 with 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz*1
- 4G+ Cat6 up to 300Mbps
- 3x RJ11 Ports (2x FXS, 1x DSL) & 5x RJ45 Gigabit Ports & 1x USB 3.0 Port
- 2x Nano SIM for 4G/LTE Failover
- VDSL2 35b: Supports 350Mbps DSL Access*2
- VDSL2/ADSL2+/ADSL2/ADSL Compatibility
- IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL VPN
- Load Balancing Across DSL, 4G, and Ethernet WAN for Optimized Connectivity
- Centralized Cloud Management
- Desktop/Wall/Rack Mounting (Purchase Rackmount Kit-D226 Separately)
Get the Higher DSL Speeds Cost-Effectively
The integrated DSL port supports VDSL2/ADSL2+/ADSL2/ADSL connections. Compatibility with the leading ISPs provides ideal IP-based connections for any small business.
Get Instant 4G+ LTE - Internet up to 300 Mbps
Versatile Connectivity
DR3650v-4G's compatible with Super VDSL (VDSL2 Profile 35b), Ethernet access, and 4G/3G USB modems. Its Gigabit LAN/WAN port accepts connections from cable or fiber modems, and the FXS ports supports VoIP for reliable voice communication. The USB 3.0 port supports 4G/3G dongles for a solid main or backup internet connection.
Up to 3.0 Gbps Business-Level Wi-Fi 6 Empowers Small and Medium Business*
HE 160
Double the data at peak transmission times on a single stream
OFDMA
Enables different devices to share one transmission stream, increasing efficiency
1024 QAM
25% more data encoded at one time
Software Defined Networking (SDN) with Cloud Access
Centralised cloud management for Omada gateways, switches, and access points across multiple sites, with the Omada cloud-based controller offering the Essentials version of cloud services for free, reducing maintaince costs.
High-Security and High-Performance VPN
SSL/ IPSec / GRE / WireGuard / PPTP / L2TP VPN & OpenVPN easily build secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study from home.
In the Box
Build Features
Specifications
SECURITY
Access Control
Source/Destination IP Based Access Control
Filtering
Web Group Filtering*5
URL Filtering
Web Security*5
ARP Inspection
Sending GARP Packets
ARP Scanning*5
IP-MAC Binding
Attack Defense
TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN
HARDWARE FEATURES
Interface
1× Gigabit WAN/LAN Port
4× Gigabit LAN Ports
1× DSL Port
2× FXS Ports
1× USB 3.0 (supports USB LTE dongle and USB Storage)
Dual Nano SIM Slot (4G+ Cat6)
Button
Reset Button
Power Supply
12V DC / 3.3A Power Adapter
Wi-Fi Frequency & Signal Rate
2.4 GHz: 574 Mbps
5 GHz: 2402 Mbps (HE160)
Flash
256 MB NAND
DRAM
512 MB DDR4
Dimensions ( W x D x H )
8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not included)
Antenna
Wi-Fi: 3× 5GHz 5dBi & 2.4GHz 3.5dBi dual-band detachable antennas
LTE: 2× 4.0dBi omnidirectional detachable antennas
Mounting
Desktop/Wall-mounting/Rackmount (with Kit-D226, sold separately)
Max. Power Consumption
Power adapter not included: 28.482 W (Full load + USB)
Power adapter included: 31.42 W (Full load + USB)
PERFORMANCE
GRE
Unencrypted: 541.8Mbp
Encrypted: 289.2Mbps
WireGuard VPN
311.6Mbps
Concurrent Session
150,000
New Sessions /Second
3,800
NAT (Static IP)
937.2 Mbps / 936.1Mbps
NAT(DHCP)
945.8 Mbps / 940.6Mbps
NAT(PPPoE)
942.9 Mbps / 942.9Mbps
NAT (L2TP)
837.4 Mbps / 881.5Mbps
NAT (PPTP)
803.0 Mbps / 910.5 Mbps
IPsec VPN Throughput
ESP-SHA1-AES256: 569.9Mbps
ESP-SHA256-AES256: 543.3Mbps
ESP-SHA384-AES256: 549.0Mbps
ESP-SHA512-AES256: 539.3Mbps
OpenVPN
129.3Mbps
L2TP VPN Throughput
Unencrypted: 909.4 Mbps
Encrypted: 494.9Mbps
PPTP VPN Throughput
Unencrypted: 897.5 Mbps
Encrypted: 190.8 Mbps
SSL VPN Throughput
126.7Mbps
66 Byte Packet Forwarding Rate
1,453,489 pps / 1,453,488 pps
1,518 Byte Packet forwarding rate
81,274 pps / 91,275 pps
WIRELESS FEATURES
Advanced Features
Seamless Roaming
Mesh (with EAP that supports Mesh)
OFDMA
Beamforming
Enable/Disable SSID Broadcast
Enable/Disable Wireless Radio
MU-MIMO
Load Balance
Automatic Channel Selection Algorithm
Airtime Fairness
Rate Limit: Based on SSID/Client
Transmit Power Control: Adjust transmit Power on dBm
Multiple SSIDs: 16 in total (8 per radio)
Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
Guest Network
Support
BASIC FUNCTIONS
WAN Connection Type
Static IP
Dynamic IP
PPPoE (supports MRU Configuration)
PPTP
L2TP
MAC Clone
Modify WAN Address
DHCP
DHCP Server
DHCPv6 PD Server (only in Standalone Mode)
DHCP Options Customization
DHCP Address Reservation
Multi-IP Interfaces
Multi-Net DHCP
IPv6
StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
VLAN
802.1Q VLAN
IPTV
IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Advanced Features
Advanced Routing
Static Routing
Policy Routing
RIP*5
OSPF*5
Bandwidth Control
IP-Based Bandwidth Control
Load Balance
Intelligent Load Balance
Application Optimized Routing
Link Backup(Timing, Failover)
Online Detection
NAT
One-to-One NAT
Multi-Net NAT
Virtual Server
Port Triggering*5
NAT-DMZ
FTP/H.323/SIP/IPSec/PPTP ALG
UPnP
Session Limit
IP-Based Session Limit
VPN
GRE
Only in Standalone Mode
SSL VPN
50 Tunnels
IPsec VPN
100 IPSec VPN Tunnels
LAN-to-LAN, Client-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
IPsec Failover
IKE v1/v2
MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
NAT Traversal (NAT-T)
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)
PPTP VPN
PPTP VPN Server
PPTP VPN Client (10)*6
50 Tunnels
PPTP with MPPE Encryption
L2TP VPN
L2TP VPN Server
L2TP VPN Client (10)*6
50 Tunnels
L2TP over IPSec
OpenVPN
OpenVPN Server
OpenVPN Client (5)*6
55 OpenVPN Tunnels
"Certificate + Account" Mode
Full Mode
WireGuard VPN
Yes
AUTHENTICATION
Web Authentication
No Authentication
Simple Password*6
Hotspot (Local User / Voucher*6 / SMS*6 / Radius*6)
External Radius Sever
External Portal Sever*6
LDAP
Management Features
Omada App
Yes
Centralized Management
Omada Cloud-Based Controller
Omada Hardware Controller
Omada Software Controller
Cloud Access
Yes. Require the use of Omada Controller.
Service
Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
Maintenance
Web Management Interface
Remote Management
Export & Import Configuration
SNMP v1/v2c/v3
Diagnostics (Ping & Traceroute)*5
NTP Synchronize*5
Port Mirroring
CLI (only in Standalone Mode)
Syslog Support
TR-069 (data models of TR-098 and TR181 are supported)
Zero-Touch Provisioning
Yes. Require the use of Omada Controller.
Management Features
Automatic Device Discovery
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration
OTHERS
Certification
CE, RoHS
Package Content
DR3650v-4G
Power Adapter
Ethernet Cable
Phone Cable
Quick Installation Guide
System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
MAC OS, NetWare, UNIX or Linux
Environment
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity: 10% to 90% non-condensing
Storage Humidity: 5% to 90% non-condensing
Notes
*1Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and coverage are not guaranteed and will vary.
*2Maximum wired signal rates are the physical rates. Actual data throughput is not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors.
*3Omada Mesh Technology requires the use of EAPs that support mesh functionality. Please refer to https://www.tp-link.com/en/omada-mesh/product-list/ to confirm which Omada EAPs are compatible with Omada Mesh. Additionally, ER706W also supports standalone Mesh. Please refer to https://www.tp-link.com/en/standalonemesh/product-list/ to confirm the models that support standalone Mesh.
*4Use of Wi-Fi 6 (802.11ax) and its features, including OFDMA, HE160, and 1024-QAM, require clients to support the corresponding features. The 160 MHz bandwidth is only available on the 5 GHz band. It may be unavailable in some regions/countries due to regulatory restrictions.
*5Supported only in Standalone Mode.
*6Supported only in Controller Mode.
*7The Omada cloud-based controller offers the Essentials version of cloud services for free, while the Standard version, which includes advenced features, requires a license.
