TP-Link Omada EAP625-Outdoor HD (AX1800) Dual-Band 4-Stream High-Density IP67 Outdoor Wi-Fi 6 Access Point with 1GbE x1 (PoE+ 13W)
Out of stock
TP-Link Omada EAP625-Outdoor HD (AX1800) Dual-Band 4-Stream High-Density IP67 Outdoor Wi-Fi 6 Access Point with 1GbE x1 (PoE+ 13W)
- Brand: TP-Link
- MPN: EAP625-Outdoor HD
- Part #: NAPTPL0625
- UPC:
View all shipping info
- Brand: TP-Link
- MPN: EAP625-Outdoor HD
- Part #: NAPTPL0625
- UPC:
Product is out of stock. View similar products in-stock at PB Tech
Features
EAP625-Outdoor HD
AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
- Up to 1.8 Gbps WiFi 6 Speeds: 574 Mbps on 2.4 GHz + 1201 Mbps on 5 GHz.*1
- Supports WiFi 6 technologies, such as 1024-QAM, OFDMA, etc.*2
- High-density connectivity up to 1,000+ clients.*3
- Long-range coverage with the high-power amplifier and 2× detachable antennas.
- IP67 weatherproof enclosure for various outdoor environments.
- Advanced Functions: Centralized management, Omada mesh, and seamless roaming.*4
- PoE+ Powered: Supports both 802.3at PoE (adapter not included).
High-Performance Wi-Fi 6
Powered by the latest WiFi 6 technologies, such as MU-MIMO and 1024 QAM, our EAP625-Outdoor HD brings speeds up to 1.8 Gbps.
Long Distance Starts with External Antennas
Two detachable external antennas for 5 GHz and 2.4 GHz provide optimal coverage and greater flexibility for your network.
Ideal for High-Density Outdoor Scenes
FDMA and MU-MIMO provide simultaneous connections for dozens of clients in large open areas.
Equipped with an IP67 weatherproof enclosure, our EAP625-Outdoor HD withstands the most extreme environments.
- IP67 Weatherproof Enclosure
- 6KV Lightning Protection
Flexible Deployment with Omada Mesh and PoE Support
Seamless Integration into Omada SDN
1. Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range, coverage, and maximum quantity of connected devices are based on test results under normal usage conditions. Actual wireless data throughput, wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles; 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead; and 3) client limitations, including rated performance, location, connection quality, and client condition.
2. Use of WiFi 6 (802.11ax) and its features, including OFDMA, 1024-QAM, and more, requires clients to support the corresponding features.
3. The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
4. Omada Mesh, Seamless Roaming, Cloud Access, and Captive Portal require the use of Omada SDN controllers. Go to Omada Mesh Product List to find all the models supported by Omada mesh technology, and refer to the User Guides for Omada SDN Controllers for configuration methods.
5. The dimension information only includes the product and bracket and excludes the detachable external antennas.
6. Based on field tests. The number listed here is the maximum distance of one EAP625-Outdoor HD can reach and connect the devices. The real transmission range and recommended coverage may vary, according to the environment, receiving device, etc.
Specifications
Reviews
Accessories
Delivery & Pick-up
.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security and Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
Delivery Estimates
The delivery time-frame (in days) for each product we sell is detailed on the individual product page just to the right of the main product image. From when you place your order, for DHL express delivery in-stock products typically arrive within 2-3 working days for metro areas and 3-5 working days for rural areas. For Standard delivery in-stock products typically arrive within 3-7 working days for NSW, VIC, ACT, QLD and SA deliveries and 5-10 working days for WA, TAS and NT.
Overseas Shipments
If you are located in New Zealand, you can order directly from our New Zealand site www.pbtech.co.nz. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Outdoor Access Points
TP-Link Omada EAP225-Outdoor (AC1200) Dual-Band Wi-Fi 5 Access...
Ubiquiti UniFi UAP-AC-M (AC1200) Dual-Band 4-Stream WiFi 5 Access...
TP-Link Omada EAP110-Outdoor (N300) 2.4GHz 2-Stream IP65 Outdoor...
Ubiquiti UniFi U6-Mesh (AX5400) Dual-Band 6-Stream Wi-Fi 6 Access...
Ubiquiti NanoStation LocoM5 Outdoor airMAX CPE 5GHz, 150+ Mbps,...
TP-Link Omada EAP625-Outdoor HD (AX1800) Dual-Band 4-Stream High-Density IP67 Outdoor Wi-Fi 6 Access Point with 1GbE x1 (PoE+ 13W)
- Brand: TP-Link
- MPN: EAP625-Outdoor HD
- Part #: NAPTPL0625
Product URL: https://www.pbtech.com/au/product/NAPTPL0625/TP-Link-Omada-EAP625-Outdoor-HD-AX1800-Dual-Band-4
Features
EAP625-Outdoor HD
AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
- Up to 1.8 Gbps WiFi 6 Speeds: 574 Mbps on 2.4 GHz + 1201 Mbps on 5 GHz.*1
- Supports WiFi 6 technologies, such as 1024-QAM, OFDMA, etc.*2
- High-density connectivity up to 1,000+ clients.*3
- Long-range coverage with the high-power amplifier and 2× detachable antennas.
- IP67 weatherproof enclosure for various outdoor environments.
- Advanced Functions: Centralized management, Omada mesh, and seamless roaming.*4
- PoE+ Powered: Supports both 802.3at PoE (adapter not included).
High-Performance Wi-Fi 6
Powered by the latest WiFi 6 technologies, such as MU-MIMO and 1024 QAM, our EAP625-Outdoor HD brings speeds up to 1.8 Gbps.
Long Distance Starts with External Antennas
Two detachable external antennas for 5 GHz and 2.4 GHz provide optimal coverage and greater flexibility for your network.
Ideal for High-Density Outdoor Scenes
FDMA and MU-MIMO provide simultaneous connections for dozens of clients in large open areas.
Equipped with an IP67 weatherproof enclosure, our EAP625-Outdoor HD withstands the most extreme environments.
- IP67 Weatherproof Enclosure
- 6KV Lightning Protection
Flexible Deployment with Omada Mesh and PoE Support
Seamless Integration into Omada SDN
1. Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range, coverage, and maximum quantity of connected devices are based on test results under normal usage conditions. Actual wireless data throughput, wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles; 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead; and 3) client limitations, including rated performance, location, connection quality, and client condition.
2. Use of WiFi 6 (802.11ax) and its features, including OFDMA, 1024-QAM, and more, requires clients to support the corresponding features.
3. The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
4. Omada Mesh, Seamless Roaming, Cloud Access, and Captive Portal require the use of Omada SDN controllers. Go to Omada Mesh Product List to find all the models supported by Omada mesh technology, and refer to the User Guides for Omada SDN Controllers for configuration methods.
5. The dimension information only includes the product and bracket and excludes the detachable external antennas.
6. Based on field tests. The number listed here is the maximum distance of one EAP625-Outdoor HD can reach and connect the devices. The real transmission range and recommended coverage may vary, according to the environment, receiving device, etc.
Specifications
HARDWARE FEATURES
Interface
1x Gigabit Ethernet Port
Button
Reset
Power Supply
- 802.3at PoE
- 48V Passive PoE
Note: PoE adapter is not included.
Dimensions ( W x D x H )
11.0 x 7.2 x 2.2 in (280.4 × 182.2 × 56.9 mm)*5
Antenna Type
2× External Dual-Band Omni Antennas
- 2.4 GHz: 3.0 dBi;
- 5 GHz: 5.0 dBi
Weatherproof Enclosure
IP67
Mounting
Pole/Wall Mounting (Kits included)
WIRELESS FEATURES
Concurrent Clients
1,000 *3
Wireless Standards
IEEE 802.11 a/b/g/n/ac/ax
Frequency
5 GHz, and 2.4 GHz
Signal Rate
- 5 GHz: Up to 1201 Mbps
- 2.4 GHz: Up to 574 Mbps
Wireless Functions
- Mesh*4
- Seamless Roaming*4
- Automatic Channel Assignment
- Load Balance
- Band Steering
- Beamforming
- Airtime Fairness
- Multiple SSIDs:16 (8 for each band)
- Wireless Statistics
- Wireless Schedule
- Reboot Schedule
- RADIUS Accounting
- MAC Authentication
- Static IP/Dynamic IP
Wireless Security
- VLAN
- Access Control
- Rogue AP Detection
- Captive Portal Authentication*4
- Maximum number of MAC Filter: 4,000
- Wireless Isolation between Clients
- WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- 802.1X Support
Transmission Power
- CE: < 20 dBm (2.4 GHz, EIRP), < 30 dBm (5 GHz, EIRP);
- FCC: < 25 dBm (2.4 GHz), < 25 dBm (5 GHz)
MANAGEMENT
Omada App
Yes
Restore & Backup
Yes
Firmware update via Web
Yes
NTP
Yes
Centralized Management
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
- Omada Cloud-Based Controller
Cloud Access
Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller.
Email Alerts
Yes
LED ON/OFF Control
Yes
Management MAC Access Control
Yes
SNMP
v1, v2c, v3
SSH
Yes
Web-based Management
Yes
OTHERS
Certification
CE, FCC, RoHS
Package Contents
- EAP625-Outdoor HD
- 2× Detachable Antennas
- Installation Guide
- Mounting Kit
- Waterproof Kit
Environment
- Operating Temperature: -30 °C-70 °C (-22 °F-158 °F);
- Storage Temperature: -40 °C-70 °C (-40 °F-158 °F);
- Operating Humidity: 10%-90% non-condensing;
- Storage Humidity: 5%-90% non-condensing
