Allied Telesis 1000LX SFP Module to 40Km SingleMode LC 1310nm
Out of stock
Allied Telesis 1000LX SFP Module to 40Km SingleMode LC 1310nm
- Brand: Allied Telesis
- MPN: AT-SPLX40
- Part #: NETATS1231
- UPC:
View all shipping info
- Brand: Allied Telesis
- MPN: AT-SPLX40
- Part #: NETATS1231
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Other Networking





Allied Telesis 1000LX SFP Module to 40Km SingleMode LC 1310nm
- Brand: Allied Telesis
- MPN: AT-SPLX40
- Part #: NETATS1231

Product URL: https://www.pbtech.com/au/product/NETATS1231/Allied-Telesis-1000LX-SFP-Module-to-40Km-SingleMod
Features
SPLX40 -1000EX (LC) single-mode, 40km
The SPLX40 offers a long-haul option to extend your network up to 40km.
Allied Telesis AT-SPLX40 Compatible 1000BASE-EX SFP Transceiver Module (SMF, 1310nm, 40km, LC, DDM)
Optcore's OSP1250-3140DCR-ATE is a high performance and cost-effective small form factor pluggable (SFP) transceiver for 1000BASE-EX Gigabit Ethernet and 1G Fiber Channel application. It fully complies with the SFP Multi-Sourcing Agreement (MSA) and can be used on the MSA compliant networking equipment. The 1000BASE-LX SFP transceiver is tested to be compatible with Allied Telesis networking equipment including Ethernet Switches, Ethernet Routers, Network Interface Cards (NICs) and Media Converters. The SFP transceiver is an ideal equivalent to Allied Telesis AT-SPLX40 1000BASE-EX SMF 1310nm 40km SFP Transceiver but with much lower price, which provides a reliable compatible SFP transceiver solution for system integrator, distributors and end users in network infrastructure and fiber cabling.
-Functionally identical to Allied Telesis AT-SPLX40 1000BASE-EX SFP module
-Far less price than OEM transceiver
-Built-in digital diagnostic monitoring interface for real-time monitoring of operating parameters
-Single 3.3V power supply
-Low power dissipation
-ROHS compliant and Lead-Free
Specifications
Allied Telesis Genuine
AT-SPLX40
Vendor Name
FS
Form Factor
SFP
Max Data Rate
1000Mbps
Wavelength
1310nm
Max Cable Distance
40km
Connector
LC duplex
Optical Components
DFB 1310nm
Media
SMF
DOM Support
Yes
TX Power
-5 ~ 0dBm
Receiver Sensitivity
< -24dBm
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Protocols
SFF-8472 MSA Compliant, IEEE 802.3ah-2004
