Features
1000Base-BX WDM Bi-Directional SFP Module TL-SM321A
TP-LINK's TL-SM321A adopts the latest standard 1000Base-BX, transmission over a single strand of fiber, with one different wavelength going in each direction. You can extend the network distance up to 10Km with TP-LINK's Routers, Switches, Media Converters to provide high speed and stability.
-Supports WDM Bi-Directional technology, using a single strand of fiber
-TX: 1550nm / RX: 1310nm
-Internal +3.3V Power Supply
-In pairs with TL-SM321B
-Plug-and-Play
-Suitable Products: TL-SG5428, TL-SL5428E, TL-SG3210/3216/3424/3424P, TL-SL3428/3452, TL-SG2216/2424, TL SL2210WEB/2218WEB/2428WEB/2452WEB, TL-SL1351 and MC200L
Specifications
MEDIA CONVERTER & MODULE
Standards and Protocols
IEEE 802.3z, CSMA/CD, TCP/IP
Wave Length
TX: 1550nm / RX: 1310nm
Cabel
Single-mode Fiber
Power Supply
3.3V
Fiber Type
9/125 um Single-mode
Max. Cable Length
10km
Data Rate
1.25Gbps
Port Type
LC
Safety & Emission
FCC, CE
Environment
Operating Temperature:
0~70C (32~158F)
Storage Temperature:
-40~80C (-40~176F)
Operating Humidity:
10%~90% non-condensing
Storage Humidity:
5%~90% non-condensing
