TP-Link FC111PB-20 10/100 Mbps WDM Media Converter with 1-Port PoE - Fiber SC - RJ45, Single-mode, Up to 20km

PB Tech price

$ 48 .39

+GST

$ 53 .23

inc GST

Out of stock

TP-Link FC111PB-20 10/100 Mbps WDM Media Converter with 1-Port PoE - Fiber SC - RJ45, Single-mode, Up to 20km

Brand: TP-Link
MPN: FC111PB-20
Part #: NETTPL1122
UPC:

PB Tech price

$ 53 .23

inc GST

+GST inc GST

Out of stock

Delivery: Out of stock

Express Delivery Times

Metro - Within 2-3 working days

Rural - Within 3-5 working days

Standard Delivery Times

NSW, VIC, ACT, QLD - Within 3-7 working days

SA, WA, TAS, NT - Within 5-10 working days

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: TP-Link
MPN: FC111PB-20
Part #: NETTPL1122
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

TL-FC111PB-20 is a 10/100 Mbps media converter with 802.3af PoE output, providing 1× 10/100 Mbps PoE RJ45 port and 1× 100 Mbps SC fiber port, which can convert between electrical and optical signals. With up to 20 km fiber transmission distance and 802.3af PoE output, the media converter is designed to address the needs of flexible long-range surveillance deployment with optical fibers. It provides an economical path towards extending the distance of an existing network.

- Converts the data between fiber (optical signal) and copper (electric signal).
- Extends fiber distance up to 20 km.
- The 802.3af PoE output makes remote camera deployment easier and more convenient.
- WDM (Wave Division Multiplexing) technology enables to transmit and receive data over one single fiber strand instead of two.
- Wide operating temperature (0-50 ℃) with reliability.
- Auto-negotiation of Half-Duplex/Full-Duplex transfer mode.

How This Product Works

TL-FC111PB-20 adopts WDM (wavelength division multiplexing) technology, helping send and receive data at a distance of up to 20 km with only a single mode fiber, which saves half of the cable deployment cost for customers. TL-FC111PB-20 transmits data at 1310 nm wavelength and receives data at 1550 nm wavelength on optical fiber. Therefore, the terminal device used in conjunction with the TL-FC111PB-20 should send data at a wavelength of 1550 nm and receive data at a wavelength of 1310 nm. TP-Link another media converter TL-FC111A-20 is one of the products that can cooperate with TL-FC111PB-20.

Other Features

Besides, this media converter can be used as a standalone device (no rack required) or used with TP-Link's TL-FC1420 rack for auto MDI/MDI-X in TX port in which duplex mode is automatically negotiated.

PoE Output Port, Auto-Negotiation (10/100 Mbps)

Easy to Connect PoE Devices with Fiber and PoE Output

Transmit and Receive Data over One Single-Mode Fiber with SC Interface

10/100 Mbps Media Converter - Ideal for Surveillance Deployment

Specifications

NETWORK

Standards and Protocols

IEEE802.3, IEEE802.3i, IEEE802.3u

ENVIRONMENT

Operating Temperature

0-50 °C (32-122 °F)

Storage Temperature

-40-70 °C (-40-158 °F)

Operating Humidity

10-90% RH non-condensing

Storage Humidity

5-90% RH non-condensing

HARDWARE FEATURES

Interface

1x 10/100 Mbps PoE RJ45 port (Auto MDI/MDIX)
1x 100 Mbps SC fiber port

Network Media

100BASE-Tx: 2-pair UTP/STP of Cat. 5 or above (≤100 m)

Power Supply

48 V/0.5 A

LED

PWR, Link/Act, PoE

Dimensions ( W x D x H )

3.7 x 2.9 x 1.1 in (94.5 x 73.0 x 27.0 mm)

Wave Length

1310 nm TX, 1550 nm RX

ANTENNA

Connector Type

1x 10/100 Mbps PoE RJ45 port
1x 100 Mbps SC fiber port

MEDIA CONVERTER & MODULE

Fiber Type

9/125 μm single-mode fber (<=20 km)

OTHERS

Package Contents

Media Converter TL-FC111PB-20
Power Adapter
Installation Guide

Manufacturer Part No:

FC111PB-20

Brand:

TP-Link

Product Type:

10/100 Mbps WDM Media Converter with 1-Port PoE

UPC

Product Family:

Shipping Weight:

0.3 kg

PB Part No:

NETTPL1122

Product Model:

FC111PB-20

Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
