TP-Link Omada ER707-M2 2.5G Multi-WAN VPN Gateway (Rackmountable)
SFP x1 / 2.5GbE x2 / 1GbE x5 / USB 2.0 x1
TP-Link Omada ER707-M2 2.5G Multi-WAN VPN Gateway (Rackmountable)
SFP x1 / 2.5GbE x2 / 1GbE x5 / USB 2.0 x1
- Brand: TP-Link
- MPN: ER707-M2
- Part #: NETTPL25707
- UPC:
View all shipping info
- Brand: TP-Link
- MPN: ER707-M2
- Part #: NETTPL25707
- UPC:
Features
Dual 2.5 Gbps Ports, Engineered for Dense Environments
Delivering high-speed transmissions through dual 2.5 Gbps ports, ER707-M2 is designed for multi-person environments such as retail stores, hotels, and offices. Enjoy a blazing-fast network experience while working from home.
6× WAN Ports & 1 USB WAN for Mobile Broadband
Empowered with up to 6× WAN SFP and RJ45 ports, ER707-M2 supports various internet access.? Multi-WAN Load Balancing distributes data streams based on the bandwidth proportion of every WAN port to increase the utilization rate of multi-line broadband.
Connect a 4G/3G modem to the USB 2.0 port for a LTE WAN backup.
High-Security VPN
Pass-through traffic and a variety of VPN protocols, such as SSL, GRE§, IPSec, PPTP, and L2TP, are available on ER707-M2, giving consumers versatile options. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment.* The router also features a built-in hardware engine to boost VPN performance.
Internet Access Management Strategy
Standardize users' online behavior and easily specify the internet access rights and strategies of employees via IP/MAC/URL Filtering and Access Control List (ACL). Captive Portal authentication facilitates network resource control by capturing, authenticating, and classifying user access. Appropriate network resources can also be allocated for particular users or guests.
Omada SDN-The Smarter Cloud Solution for Business Networking
As the router that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, ER707-M2 allows for remote and centralized management, anywhere, anytime. Standalone management via the Web UI or app is also available to maximize convenience.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
Specifications
Reviews
Accessories
Delivery & Pick-up
.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security and Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
Delivery Estimates
The delivery time-frame (in days) for each product we sell is detailed on the individual product page just to the right of the main product image. From when you place your order, for DHL express delivery in-stock products typically arrive within 2-3 working days for metro areas and 3-5 working days for rural areas. For Standard delivery in-stock products typically arrive within 3-7 working days for NSW, VIC, ACT, QLD and SA deliveries and 5-10 working days for WA, TAS and NT.
Overseas Shipments
If you are located in New Zealand, you can order directly from our New Zealand site www.pbtech.co.nz. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular HyperFibre Routers
Ubiquiti UniFi (UCG-Fiber) 10G Cloud Gateway Fiber (SSD Tray not...
ASUS TUF-AX6000 (AX6000) Dual-Band WiFi 6 Extendable Gaming...
Ubiquiti UniFi (UDR7) Dream Router 7 10G Cloud Gateway with NVR...
Ubiquiti UniFi (UDM-PRO) Dream Machine Pro 10G Cloud Gateway with...
TP-Link Deco BE65 (BE11000) Tri-Band WiFi 7 Whole Home Mesh...
TP-Link Omada ER707-M2 2.5G Multi-WAN VPN Gateway (Rackmountable) SFP x1 / 2.5GbE x2 / 1GbE x5 / USB 2.0 x1
- Brand: TP-Link
- MPN: ER707-M2
- Part #: NETTPL25707
Product URL: https://www.pbtech.com/au/product/NETTPL25707/TP-Link-Omada-ER707-M2-25G-Multi-WAN-VPN-Gateway-R
Features
Dual 2.5 Gbps Ports, Engineered for Dense Environments
Delivering high-speed transmissions through dual 2.5 Gbps ports, ER707-M2 is designed for multi-person environments such as retail stores, hotels, and offices. Enjoy a blazing-fast network experience while working from home.
6× WAN Ports & 1 USB WAN for Mobile Broadband
Empowered with up to 6× WAN SFP and RJ45 ports, ER707-M2 supports various internet access.? Multi-WAN Load Balancing distributes data streams based on the bandwidth proportion of every WAN port to increase the utilization rate of multi-line broadband.
Connect a 4G/3G modem to the USB 2.0 port for a LTE WAN backup.
High-Security VPN
Pass-through traffic and a variety of VPN protocols, such as SSL, GRE§, IPSec, PPTP, and L2TP, are available on ER707-M2, giving consumers versatile options. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment.* The router also features a built-in hardware engine to boost VPN performance.
Internet Access Management Strategy
Standardize users' online behavior and easily specify the internet access rights and strategies of employees via IP/MAC/URL Filtering and Access Control List (ACL). Captive Portal authentication facilitates network resource control by capturing, authenticating, and classifying user access. Appropriate network resources can also be allocated for particular users or guests.
Omada SDN-The Smarter Cloud Solution for Business Networking
As the router that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, ER707-M2 allows for remote and centralized management, anywhere, anytime. Standalone management via the Web UI or app is also available to maximize convenience.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
Specifications
HARDWARE FEATURES
Standards and Protocols
- IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
- TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
Interface
- 1× 2.5G RJ45 WAN Port
- 1× 2.5G RJ45 WAN/LAN Port
- 1× Gigabit SFP WAN/LAN Port
- 4× Gigabit RJ45 WAN/LAN Ports
- 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle)
Network Media
- 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
- 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
Fan Quantity
Fanless
Button
Reset Button
Power Supply
12V/1.5A Adapter
Flash
128MB NAND
DRAM
1 GB DDR4
LED
PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act)
Dimensions ( W x D x H )
8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
Protection
4 kV surge protection
Enclosure
Steel
Mounting
Desktop/Wall Mounting
Max Power Consumption
14.2 W (with USB2.0 connected)
7.1 W (without USB2.0 connected)
PERFORMANCE
Concurrent Session
500,000
New Sessions /Second
4,200
NAT (Static IP)
2364.45 Mbps / 2343.28 Mbps
NAT(DHCP)
2364.24 Mbps / 2326.21 Mbps
NAT(PPPoE)
2350.93 Mbps / 2125.83 Mbps
NAT (L2TP)
1249.04 Mbps / 831.12 Mbps
NAT (PPTP)
1169.23 Mbps / 1175.52 Mbps
IPsec VPN Throughput
- ESP-MD5-AES256: 537.12 Mbps
- ESP-SHA1-AES256: 754.65 Mbps
L2TP VPN Throughput
- Unencrypted: 1442.65 Mbps
- Encrypted: 346.43 Mbps
SSL VPN Throughput
142.99 Mbps
66 Byte Packet forwarding rate
1832.69 Mbps / 1741.84 Mbps
1,518 Byte Packet forwarding rate
2461.18 Mbps / 2457.32 Mbps
BASIC FUNCTIONS
WAN Connection Type
- IPv4_Static IP
- IPv4_Dynamic IP
- IPv4_PPPOE
- IPv4_L2TP
- IPv4_PPTP
- IPv6_PPP
- IPv6_DHCPv6
- IPv6_Static IP
- IPv6_6in4
- IPv6_Pass-Through
- Mobile Broadband: 4G/3G modem for backup via USB port
MAC Clone
Modify WAN/LAN MAC Address†
DHCP
- DHCP Server/Client
- DHCP Address Reservation
- Multi-IP Interfaces*
- Multi-Net DHCP*
IPv6
WAN Connection
VLAN
802.1Q VLAN
IPTV
IGMP v2/v3 Proxy
ADVANCED FUNCTIONS
Advanced Routing
- Static Routing
- Policy Routing
Bandwidth Control
- IP/Port-based Bandwidth Control
- Guarantee & Limited Bandwidth
Load Balance
- Intelligent Load Balance
- Application Optimized Routing
- Link Backup (Timing§, Failover)
- Online Detection
NAT
- One-to-One NAT§
- Multi-Net NAT
- Virtual Server
- Port Triggering§
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP
Session Limit
IP-based Session Limit
VPN
IPsec VPN
- 100 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm
- IKEv1/v2
- MD5, SHA1 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)
PPTP VPN
- PPTP VPN Server
- PPTP VPN Clients (12)
- 60 Tunnels (Shared with L2TP)
- PPTP with MPPE Encryption
L2TP VPN
- L2TP VPN Server
- L2TP VPN Clients (12)
- 60 Tunnels (Shared with PPTP)
- L2TP over IPSec
OpenVPN
- OpenVPN Server
- OpenVPN Clients (6)
- 66 OpenVPN Tunnels*
SECURITY
Filtering
- WEB Group Filtering§
- URL Filtering
- Web Security§
ARP Inspection
- Sending GARP Packets§
- ARP Scanning§
- IP-MAC Binding§
Attack Defense
- TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN
Access Control
Source/Destination IP Based Access Control
AUTHENTICATION
Web Authentication
- No Authentication
- Simple Password*
- Hotspot (Local User/Voucher* /SMS*/Radius*)
- External Radius Sever
- External Portal Sever*
MANAGEMENT
Omada App
Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
Cloud Access
Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Service Dynamic
DNS (Dyndns, No-IP, Peanuthull, Comexe)
Maintenance
- Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3*
- Diagnostics (Ping & Traceroute)§
- NTP Synchronize§
- Syslog Support
Zero-Touch Provisioning
Yes. Requiring the use of Omada Cloud-Based Controller.
Management Features
- Automatic Device Discovery
- Intelligent Network Monitoring
- Abnormal Event Warnings
- Unified Configuration
- Reboot Schedule
- Captive Portal Configuration
- ZTP (Zero-Touch Provisioning)
OTHERS
Certification
CE, FCC, RoHS
Package Contents
- ER707-M2
- Power Adapter
- Quick Installation Guide
System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Environment
- Operating Temperature: 0-40 ? (32-104 ?);
- Storage Temperature: -40-70 ? (-40-158 ?)
- Operating Humidity: 10-90% RH non-condensing
- Storage Humidity: 5-90% non-condensing
