TP-Link SM5110-SR 10G SFP+ to LC Multi-Mode Transceiver (Up to 300m over OM3)
Out of stock
TP-Link SM5110-SR 10G SFP+ to LC Multi-Mode Transceiver (Up to 300m over OM3)
- Brand: TP-Link
- MPN: SM5110-SR
- Part #: NETTPL51101
- UPC:
View all shipping info
- Brand: TP-Link
- MPN: SM5110-SR
- Part #: NETTPL51101
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Transceivers
TP-Link SM5110-SR 10G SFP+ to LC Multi-Mode Transceiver (Up to 300m over OM3)
- Brand: TP-Link
- MPN: SM5110-SR
- Part #: NETTPL51101
Product URL: https://www.pbtech.com/au/product/NETTPL51101/TP-Link-SM5110-SR-10G-SFP-to-LC-Multi-Mode-Transce
Features
10GBase-SR SFP+ LC Transceiver
The TL-SM5110-SR is designed to extend transfer distances based on 10Gbps Ethernet connectivity. It is a 10GBASE-SR high performance 850nm multi-mode SFP+ transceiver. It supports full duplex, 10G Ethernet connections up to 300m or 33m with 50/125µm or 62.5/125µm fiber cables respectively.
- Multi-mode SFP+ LC Transceiver
- Hot-Pluggable with maximum flexibility
- Supports Digital Diagnostic Monitoring (DDM)
- Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+ MSA)
- Compatible with switches with 10G SFP+ ports, like JetStream TL-SG3428X, TL-SG3428XMP, and more.

Works with Devices with 10G SFP+ Interfaces

10GbE Fiber Connection without Speed Loss, up to 300 m Transmission Distance

High Reliability with Reliable Quality

TP-Link SFP+ Module: Ultra-Fast and Reliable Fiber Connections

Specifications
Hardware Features
DDM
Yes
SFP-MSA
Yes
Hot Swappable
Yes
Media Converter & Module
Dimensions (W*D*H)
2.4*0.6*0.5 in (61.3*14.5*12.2 mm)
Transceiver
Standards and Protocols
IEEE 802.3ae, TCP/IP, SFF-8472
Wave Length
850nm
Power Supply
3.3V
Fiber Type
50/125um or 62.5/125um Multi-mode
Max. Cable Length
300m (OM3)
Data Rate
10Gbps
Port Type
LC/UPC
Safety & Emission
FCC, CE
Environment
Operating Temperature:
0-70 ℃ (32-158 ℉)
Storage Temperature:
-40-80 ℃ (-40-176 ℉)
Operating Humidity:
10-90% RH non-condensing
Storage Humidity:
5-90% RH non-condensing
Package Contents
Package Contents
10G SFP+ Module TL-SM5110-SR
Installation Guide
