Ubiquiti UniFi ECS-24-POE 26-Port 25G L3 Managed PoE Switch (1050W) - SFP28 x2, 10GbE PoE+++ x16, 2.5GbE PoE+++ x8
Ubiquiti UniFi ECS-24-POE 26-Port 25G L3 Managed PoE Switch (1050W) - SFP28 x2, 10GbE PoE+++ x16, 2.5GbE PoE+++ x8
- Brand: Ubiquiti
- MPN: ECS-24-POE
- Part #: SWHUBI250305
- UPC:
View all shipping info
- Brand: Ubiquiti
- MPN: ECS-24-POE
- Part #: SWHUBI250305
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security and Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
Delivery Estimates
The delivery time-frame (in days) for each product we sell is detailed on the individual product page just to the right of the main product image. From when you place your order, for DHL express delivery in-stock products typically arrive within 2-3 working days for metro areas and 3-5 working days for rural areas. For Standard delivery in-stock products typically arrive within 3-7 working days for NSW, VIC, ACT, QLD and SA deliveries and 5-10 working days for WA, TAS and NT.
Overseas Shipments
If you are located in New Zealand, you can order directly from our New Zealand site www.pbtech.co.nz. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Enterprise Switches
Ubiquiti Unifi USW-Pro-XG-10-PoE 12-Port 10G L3 Managed...
Ubiquiti Unifi USW-Mission-Critical 9-Port Gigabit L2 Managed PoE...
Ubiquiti UniFi ECS-24-POE 26-Port 25G L3 Managed PoE Switch (1050W) - SFP28 x2, 10GbE PoE+++ x16, 2.5GbE PoE+++ x8
- Brand: Ubiquiti
- MPN: ECS-24-POE
- Part #: SWHUBI250305
Product URL: https://www.pbtech.com/au/product/SWHUBI250305/Ubiquiti-UniFi-ECS-24-POE-26-Port-25G-L3-Managed-P
Features
Specifications
Dimensions
442.4 x 43.7 x 496 mm
(17.4 x 1.7 x 19.5")
Port Layout
2.5 GbE RJ45
8 (All PoE+++)
10 GbE RJ45
16 (All PoE+++)
25G SFP28
2
Max. PoE Output
Up to PoE+++
Total PoE Availability
100-240V AC Shared Mode: 1,050W with (2) 600W modules
100-240V AC Redundant Mode: 450W with (2) 600W modules
200-240V AC Shared Mode: 2,250W with (2) 1,200W modules
100-120V AC Shared Mode: 1,850W with (2) 1,200W modules
200-240V AC Redundant Mode: 1,050W with (2) 1,200W modules
100-120V AC Redundant Mode: 850W with (2) 1,200W modules
Redundancy
(2) Hot-Swappable PSUs
(4) Hot-Swappable Fans
Layer 3
Yes
Form Factor
Rack mount (1U)
Etherlighting™
Yes
Performance
Switching Capacity
460 Gbps
Total Non-Blocking Throughput
230 Gbps
Forwarding Rate
342 Mpps
Supported VLANs
1,000
MAC Address Table Size
128,000
L3 Table Size
ARP Entries
128,000
IPv4 Routes
256,000
Packet Buffer Size
8 MB
Layer 3 Features
DHCP Server (Local Networks)
Yes
DHCP Relay
Yes
Inter-VLAN Routing (Local Networks)
Yes
Static Routing (Local Networks)
Yes
Layer 2 Features
LACP Port Aggregation
Yes
STP & RSTP
Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
IGMP Snooping
Yes
802.1X Control
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Egress Rate Limit
Yes
Flow Control
Yes
Storm Control
Yes
Multicast & Broadcast Rate Limiting
Yes
MAC Address Blocking
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Port Isolation
Yes
Port Mirroring
Yes
Jumbo Frames
Yes
LLDP-MED
Yes
Voice VLAN
Yes
Loop Protection
Yes
Hardware
PoE Ports
PoE+++
24
Max. PoE Wattage per Port by PSE
PoE+++
90W
Max. Power Consumption
150W (Excluding PoE Output)
2,400W (Including PoE Output)
Power Method
(2) Universal input, 100-240V AC, 50/60 Hz
Power Input Method
(2) AC input, Hot-swappable power modules
Power Supply
(2) Hot-swappable AC/DC 1,200W power modules
Supported Voltage Range
100-240V AC
Management
Ethernet
AR
Heat Dissipation (Excluding PoE Output)
511.8 BTU/hr
Weight
Without mounting brackets: 9.46 kg (20.9 lb)
With mounting brackets: 9.56 kg (21.1 lb)
Enclosure Material
SGCC steel
Supported Rack Depth
482.6 mm (19") four-post racks
Posts depths ranging from 650 to 1,000 mm (25.6-39.4")
LCM Display
1.3" touchscreen
Fan Method
(4) hot-swappable fan modules
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
ESD/EMP Protection
Air: ± 30kV, contact: ± 19kV
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Etherlighting™
Ethernet
Yes
SFP28
Yes
LEDs
Ethernet
Yes
System
Yes
Software Application Requirements
UniFi Network
Version 9.0.114 and later
