Winmate FM12Q 3G/32GB Android 9.0 12.1" Rugged Tablet 1024x768, PCAP touchscreen, Qualcomm 2.2 GHz CPU, WIFI, IP65 Wide range -30C to 50C operating temperature, Fan-Less & Robust Design, DUAL SIM with protective film, RAM Mount/VESA Mount

PB Tech price

$ 5,316 .36

+GST

$ 5,848 .00

inc GST

Winmate FM12Q 3G/32GB Android 9.0 12.1" Rugged Tablet 1024x768, PCAP touchscreen, Qualcomm 2.2 GHz CPU, WIFI, IP65 Wide range -30C to 50C operating temperature, Fan-Less & Robust Design, DUAL SIM with protective film, RAM Mount/VESA Mount

BT & GPS (with external GPS antenna), IP65,

Brand: Winmate
MPN: FM12QSS
Part #: TABWMAFM12QSS
UPC:

PB Tech price

$ 5,848 .00

inc GST

+GST inc GST

In stock at Supplier

Delivery: Order now and it ships on 03 Dec

Express Delivery Times

Metro - Within 2-3 working days

Rural - Within 3-5 working days

Standard Delivery Times

NSW, VIC, ACT, QLD - Within 3-7 working days

SA, WA, TAS, NT - Within 5-10 working days

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Winmate
MPN: FM12QSS
Part #: TABWMAFM12QSS
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

Vibration and shock-proof design ensure reliable performance

When it comes to industrial usage, Winmate FM12Q that is rugged enough to survive harsh environments is a must. Its solid enclosure proves the FM12Q's durability with MIL-STD-810H certification and IP65 rating.

PCAP Touch Screen

The FM12Q features a compact panel with a PCAP touch screen. Resistant to dirt, debris, and highly sensitive touch commands make you enjoy every touch and convenience of using the device.

High-Performance CPU

To support the next generation of IoT edge devices, FM12Q has developed a new line of processors enhanced for IoT-Qualcomm Snapdragon™ 660 Series processors. These processors build on new levels of CPU, and graphics performances with integrated IoT features, real-time performance, manageability, security, and functional safety.

Reliable computing under extreme operating temperatures

Low-power components of industrial computers prevent overheating and are less likely to achieve high temperatures in the first place.

- Qualcomm Snapdragon™ 660 octacore, 2.2 GHz CPU
- 12.1" 1024 x 768 Panel with PCAP Touch
- Field replaceable front panel to reduce service costs
- IP65 waterproof and dustproof
- Wide range -30C to 50C operating temperature

Specifications

Display

Size

12.1 inches

Type

Projected Capacitive Multi Touch

Resolution

1024x768

Panel Brightness

400 nits
800 nits(Optional)

Contrast Ratio

1000:1

View Angles

89,89,89,89

Touch Mode

With Stylus Support
With Gloves Support

System Specification

Processor

Qualcomm® Snapdragon™ 660 (Octa-Core 2.2 GHz)

Memory

3GB

Storage

32GB

Operating System

Android 9.0

WLAN

Support

WWAN

4G/LTE (Optional)

GNSS

GPS/GLONASS

Sensors

G-Sensor, Temp. Sensor

Camera

Front Camera

2MP Camera

Mechanical

Dimension

Tablet: 307 x 225 x 41 mm (12.08x 8.85 x 1.61 inches)
Docking: 202 x 245 x 52 mm (7.9 x 9.6 x 2.04 inches)

Docking Housing

Aluminum Alloy Housing

Weight

Tablet 1.7 kg (3.75 lbs)
Docking 1.6 kg (3.53 lbs)

Mounting

RAM Mount/ VESA Mount

Cooling System

Fanless Design

IO Ports

USB Port

1 x USB 3.0 Type C (OTG)(Tablet)
1 x DB9 Connector for 2 x USB 2.0 Port(Docking)

Serial Port

2 x COM Port(Docking)

LAN

1 x Gigabit LAN port(Docking)

Audio

2 x Speaker(Docking)
1 x CANBus or 1 x Audio(Docking)

SD Card Slot

1 x Micro SD Card Slot(Tablet)

SIM Card Slot

1 x Dual-Nano SIM Card Slot(Tablet)

Indicator

4 x LED Indicator
(Wi-Fi, BT, UPS battery, Screen Blanking, Heater)

Environment

Operating Humidity

5% to 95% RH, Non-Condensing

Operating Temperature

-30°C to 50°C

Storage Temperature

-30°C to 60°C

Shock

MIL-STD-810H Method 516.8 Procedure I

Vibration

MIL-STD-810H Method 514.8 Procedure I

IP rating

IP65, Compliance IEC60592

Impact

Support EN62262 IK07 Rating

ESD

Compliant with EN 61000-4-2,
Enhanced ESD to ±8kV Direct & ±15kV Air

Certification

CE, FCC

Control

Button

1 x Power Button, 5 x Function Button
(Programmable Function Key Configured by Winset)

Power

Battery

7.6V UPS Battery (2S1P)
Minimum 30 minutes

Power Rating

Docking: 10V-60V with ignition control
Tablet: 12V DC In

Manufacturer Part No:

FM12QSS

Brand:

Winmate

Product Type:

12.1" Rugged Tablet

UPC

Product Family:

FM12Q

Shipping Weight:

1 kg

PB Part No:

TABWMAFM12QSS

Product Model:

3G/32GB Android 9.0

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
