FLUKE MS2-100-IE Microscanner 2 Poe Industrial Ethernet Kit
Out of stock
FLUKE MS2-100-IE Microscanner 2 Poe Industrial Ethernet Kit
- Brand: FLUKE
- MPN: MS2100-IE
- Part #: TOLFLN53320
- UPC: 754082153320
View all shipping info
- Brand: FLUKE
- MPN: MS2100-IE
- Part #: TOLFLN53320
- UPC: 754082153320
Features
FLUKE Microscanner 2 Poe Industrial Ethernet Kit
- MicroScanner™ Cable Verifier with Industrial Ethernet Adapter
- Revolutionary Interface - Graphical wire-map, length, cable ID, and distance to fault displayed on one screen
- Multimedia Support - tests all common media types including RJ11, RJ45, and Coax, with no need for adapters
- IntelliTone Toning - Trace virtually any cable or wire pair with IntelliTone digital and analog toning (Sold separately or included in MS2-KIT)
- VDV Service Detection - verifies today's media services, including 10/100/1000 Ethernet, POTS, & PoE
- Rugged Housing - Integrated rubber holster enhances grip and makes it durable enough for the toughest jobs
- Oversized Display - Large, backlit LCD makes results crystal clear whether in bright sunshine or a dark closet
- Powered by 2x AA batteries with a battery life of up to 50 hours
All-in-One Cable Verifier for Industrial Ethernet
The Fluke Networks MS2-100-IE MicroScanner 2 Cable Verifier with Industrial Ethernet Adapter helps find common errors by displaying graphical wire maps, pair lengths, distance to fault, and far-end devices. It starts by taking results from what were four different test modes and displaying them all at once - graphical wire map, pair lengths, distance to fault, cable ID, and far-end device. What's more, its integrated RJ11, RJ45, and coax test ports support virtually any type of low-voltage cable testing with no need for awkward adapters. The result is reduced test time and technician error. That makes high-quality installations more efficient and troubleshooting easier.
Rule out service problems fast
Today's communications technicians have a lot more problems to deal with than just the cabling. They have to rule out a whole host of potential cable and service issues before determining the cause of a connection problem. Is there telephone voltage? What's the polarity? Is there an Ethernet switch at the far end? Is PoE available? MicroScanner 2 acknowledges this, giving technicians high-power vision to verify today's most common voice, data, and video services. That means faster, more comprehensive troubleshooting.
Reduce test time and user error
Yesterday's cable verification testers force users to toggle between different modes (up to four) to view all test results. This not only slows the test process but also causes user frustration and error. MicroScanner 2 has defied this convention by displaying key test results - wire map, pair lengths, distance to fault, cable ID, and far-end devices - all on one screen.
Specifications
Reviews
Delivery & Pick-up
.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security and Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
Delivery Estimates
The delivery time-frame (in days) for each product we sell is detailed on the individual product page just to the right of the main product image. From when you place your order, for DHL express delivery in-stock products typically arrive within 2-3 working days for metro areas and 3-5 working days for rural areas. For Standard delivery in-stock products typically arrive within 3-7 working days for NSW, VIC, ACT, QLD and SA deliveries and 5-10 working days for WA, TAS and NT.
Overseas Shipments
If you are located in New Zealand, you can order directly from our New Zealand site www.pbtech.co.nz. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Testing & Measurement Tools
USB Inspection Camera EndoScope 2MP, Lens Diameter: 8.5mm, Cable...
Leica Disto D2 Bluetooth ISO certified measuring engine high...
ProsKit MT-4612 Dual Infrared Laser Point Thermometer Range -50...
UGREEN UG-10950 Network & Telephone Cable Tester
ProsKit MT-7058 Wire Tester Mini Lan Ethernet Cable Tester...
FLUKE MS2-100-IE Microscanner 2 Poe Industrial Ethernet Kit
- Brand: FLUKE
- MPN: MS2100-IE
- Part #: TOLFLN53320
- UPC:754082153320
Product URL: https://www.pbtech.com/au/product/TOLFLN53320/FLUKE-MS2-100-IE-Microscanner-2-Poe-Industrial-Eth
Features
FLUKE Microscanner 2 Poe Industrial Ethernet Kit
- MicroScanner™ Cable Verifier with Industrial Ethernet Adapter
- Revolutionary Interface - Graphical wire-map, length, cable ID, and distance to fault displayed on one screen
- Multimedia Support - tests all common media types including RJ11, RJ45, and Coax, with no need for adapters
- IntelliTone Toning - Trace virtually any cable or wire pair with IntelliTone digital and analog toning (Sold separately or included in MS2-KIT)
- VDV Service Detection - verifies today's media services, including 10/100/1000 Ethernet, POTS, & PoE
- Rugged Housing - Integrated rubber holster enhances grip and makes it durable enough for the toughest jobs
- Oversized Display - Large, backlit LCD makes results crystal clear whether in bright sunshine or a dark closet
- Powered by 2x AA batteries with a battery life of up to 50 hours
All-in-One Cable Verifier for Industrial Ethernet
The Fluke Networks MS2-100-IE MicroScanner 2 Cable Verifier with Industrial Ethernet Adapter helps find common errors by displaying graphical wire maps, pair lengths, distance to fault, and far-end devices. It starts by taking results from what were four different test modes and displaying them all at once - graphical wire map, pair lengths, distance to fault, cable ID, and far-end device. What's more, its integrated RJ11, RJ45, and coax test ports support virtually any type of low-voltage cable testing with no need for awkward adapters. The result is reduced test time and technician error. That makes high-quality installations more efficient and troubleshooting easier.
Rule out service problems fast
Today's communications technicians have a lot more problems to deal with than just the cabling. They have to rule out a whole host of potential cable and service issues before determining the cause of a connection problem. Is there telephone voltage? What's the polarity? Is there an Ethernet switch at the far end? Is PoE available? MicroScanner 2 acknowledges this, giving technicians high-power vision to verify today's most common voice, data, and video services. That means faster, more comprehensive troubleshooting.
Reduce test time and user error
Yesterday's cable verification testers force users to toggle between different modes (up to four) to view all test results. This not only slows the test process but also causes user frustration and error. MicroScanner 2 has defied this convention by displaying key test results - wire map, pair lengths, distance to fault, cable ID, and far-end devices - all on one screen.
Specifications
Package Contents
In The Box
MicroScanner2 Cable Verifier with main wire-map adapter
Industrial Ethernet adapter
Multi-language getting started guide
Batteries
Fluke Networks carry pouch
General
Test connectors
Shielded 8-pin modular jack accepts 8-pin modular (RJ45) and 4-pin modular (RJ11) plugs. MicroScanner2: F-connector for coaxial cable.
Power
Battery type: 2 AA (NEDA 15A, IEC LR6) alkaline batteries
Battery life: 20 hours of typical use
Other compatible battery types: 2 AA photo lithium, NIMH, NICAD
Dimensions and weight (with batteries installed and wiremap adapter attached)
3 in x 6.4in x 1.4 in (7.6 cm x 16.3 cm x 3.6 cm) MicroScanner2: 10.6 oz (300 g) MicroScanner PoE: 10.6 oz (300 g)
Display
Monochrome LCD with backlight
Performance
Cable types tested
Twisted pair: UTP, FTP, SSTP
Coaxial (MicroScanner2): 75 O, 50 O, 93 O
Length test
Range: 460 m (1500 ft)
Resolution: 0.3 m (1 ft)
Typical accuracy: ± 4% or 0.6 m (2 ft) whichever is greater. NVP uncertainty is an additional error.
Calibration: User-settable NVP for twisted pair and coax (MicroScanner2). Can determine actual NVP with known length of cable.
Wiremap test
Detects single-wire faults, shorts, miswires, split pairs, and up to seven far-end adapter IDs. The wiremap is drawn with proportional length to visually indicate the approximate location of faults.
Ethernet port detection
MicroScanner2: Detects the advertised speed of 802.3 Ethernet ports with speeds of 10 Mbps, 100 Mbps, and 1 Gbps. MicroScanner PoE: Detects the advertised speed of 802.3 Ethernet ports with speeds of 10 Mbps, 100 Mbps, 1 Gbps, 2.5 Gbps, 5 Gbps, and 10 Gbps.
Tone generator
Supports toning and cable mapping with a Fluke Networks digital IntelliTone™ probe. Generates four tones compatible with typical analog probes. SmartTone™ feature gives positive identification of cables in bundles when using an IntelliTone or an analog probe.
Environmental
perating temperature
32 °F to 113 °F (0 °C to 45 °C)
Storage temperature
-4 °F to +140 °F (-20 °C to +60 °C)
Operating relative humidity (% RH without condensation)
90 % (50 °F to 95 °F 10 °C to 35 °C)
75 % (95 °F to 113 °F 35 °C to 45 °C)
Shock and Vibration
Random, 2 g, 5 Hz-500 Hz (Class 2)
1 m drop test with and without wiremap adapter attached
Safety
IEC 61010-1 3rd Edition
Altitude
4,000 m; Storage: 12,000 m
EMC
IEC 61326-1
