LG PCS500R Pro Centric TV Server
- Brand: LG
- MPN: PCS500R
- Part #: TVLGC99500

Product URL: https://www.pbtech.com/au/product/TVLGC99500/LG-PCS500R-Pro-Centric-TV-Server
Features
Pro:Centric® Direct Support
The stand-alone server supports LG's Pro:Centric® Direct, an HTML5 Content Management Software. This software offers a comprehensive UI (user interface) editor, along with customizable widgets and a number of theme templates to enable a unique guest experience as well as express your hotel's brand identity and individuality through LG's in-room television.
Server Admin Client
PCA or PCD Admin Client Graphical User Interface (GUI) is provided and is remotely accessible via the Internet using VPN service and a standard web browser, to provide System Integrator administration users with a full suite of features to manage and support the Pro:Centric system, including:
- System Status, Logs, and Server Settings
- Configuration for Channel Lineup and Electronic Program Guide
- UI Editor and Customization Tools
- Managing Television Settings and Software Updates
Pro:Centric® Server Installation
Remote management of this server functionality is provided via a secure, built-in VPN client that connects to the centralized VPN server, supporting remote configuration management and software updates.
Specifications
SYSTEM SOFTWARE
Software
Linux OS kernel 3.10, PCA (Java) and PCD (HTML) server applications
ELECTRICAL
Data Output
RF, 100/1000T EthernetRear Port RF/RF Tap/TTL serial, Ethernet 2 Port
DC Input
+19V DC @ 2.2Amps Adaptor
RF Output Connectors (2)
75Ohm, Type 'F'
RF Output Span
Up to 8 Channels (Typically 48-64MHz) (non-contiguous)
RF Output Frequency Range
54MHz to 865MHz
Active Output Level
-1dBm (+47.75dBmV) Typical
Test Output Level
-47.75dBm (+1dBmV) Typical
Frequency Accuracy
+/- 5 ppm
Ethernet Connector (Control Port)
10/100/1000 BaseT, RJ-45
Ethernet Connector (Feature Port)
100/1000 BaseT, Full Duplex RJ-45
TTL-UART
Command Line Interface port (5V TTL)
CPU/Memory/Storage
64-bit Intel i3-6100U (4 threads at 2.3GHz), 16GB memory, 128GB SSD/Expandable storage with M.2 NGFF or 2.5" SSD
ENVIRONMENTAL OPERATING CONDITIONS
Temperature
32° to 104° Fahrenheit
Humidity
95% Non-condensing
ENVIRONMENTAL STORAGE CONDITIONS
Storage Temperature
-4° to 158° Fahrenheit (-20° to 70° Celsius)
Humidity
95% Non-condensing
DIMENSIONS
Unit Dimensions (W × H × D)
19.0" x 1.7" x 8.5"
Unit Weight (Rack-only)
5.65 Ibs.
