APC Rack PDU 9000 Switched, ZeroU, 32A, 230V, (21) C13 & (3) C19
APC Rack PDU 9000 Switched, ZeroU, 32A, 230V, (21) C13 & (3) C19
- Brand: APC
- MPN: APDU9953
- Part #: UPSAPC9953
- UPC:
View all shipping info
- Brand: APC
- MPN: APDU9953
- Part #: UPSAPC9953
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular PDUs





APC Rack PDU 9000 Switched, ZeroU, 32A, 230V, (21) C13 & (3) C19
- Brand: APC
- MPN: APDU9953
- Part #: UPSAPC9953

Product URL: https://www.pbtech.com/au/product/UPSAPC9953/APC-Rack-PDU-9000-Switched-ZeroU-32A-230V-21-C13
Features
APC Rack PDU 9000 Switched APDU9953 - Power distribution unit (rack-mountable) - AC 230 V - 7400 VA - Ethernet 10/100/1000 - input: IEC 60309 32A - output connectors: 24 (3 x IEC 60320 C19, 21 x IEC 60320 C13) - 0U - 3.05 m cord - black
Specifications
Main
Colour
Black
Product or component type
PDU
PDU type
Switched
Cord length
3.05 m
Number of cables
1
Provided equipment
Installation guide
Rack mounting brackets
Safety guide
Complementary
Input Voltage
200...240 V
Height
182.9 cm
Width
5.6 cm
Output Voltage
200...240 V
Depth
4.6 cm
Net weight
7.34 kg
Mounting location
Side
Mounting preference
No preference
Input Plug Type
IEC 60309 32 A 2P + E
Mounting mode
Not rack-mountable
Rack units
0U
USB compatible
No
Mounting position
Vertical
Communication port protocol
SNMP
Redfish
Permissible voltage
220…240 V
Max line current
32 A
Input current limits
32 A
Load capacity
7400 VA
Network frequency
50/60 Hz
Outlet type and quantity
21 IEC 60320 C13
3 IEC 60320 C19
Communication network type
10/100/1000BASE-T
Environment
Product certifications
VDE
EAC
RCM
Standards
EN 55022 class A
EN 55024
EN 61000-3-2
EN 61000-3-3
Ambient air temperature for operation
-5…60 °C
Relative humidity
5…95 %
Operating altitude
0...10000 ft
Ambient air temperature for storage
-25…65 °C
Storage Relative Humidity
5…95 %
