PowerShield PSDR800 Defender Rackmount 800VA (480W) Line Interactive UPS, 6x NZ Power Sockets with Surge + Battery Backup, Compatible with ALL Wall Mounted Racks
PowerShield PSDR800 Defender Rackmount 800VA (480W) Line Interactive UPS, 6x NZ Power Sockets with Surge + Battery Backup, Compatible with ALL Wall Mounted Racks
- Brand: PowerShield
- MPN: PSDR800
- Part #: UPSPSD0041
- UPC:
View all shipping info
- Brand: PowerShield
- MPN: PSDR800
- Part #: UPSPSD0041
- UPC:
What PB Tech customers are saying about this product...
See More Reviews"Good and basic use for patchpanel to protect ROUTER/SWITCH/ONT. Safe product."
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular UPS - Line Interactive





PowerShield PSDR800 Defender Rackmount 800VA (480W) Line Interactive UPS, 6x NZ Power Sockets with Surge + Battery Backup, Compatible with ALL Wall Mounted Racks
- Brand: PowerShield
- MPN: PSDR800
- Part #: UPSPSD0041

Product URL: https://www.pbtech.com/au/product/UPSPSD0041/PowerShield-PSDR800-Defender-Rackmount-800VA-480W?is-review=1
Features
PowerShield has taken the smarts from our most popular range of UPSs and built them into a rack mount UPS - perfect for shallow, wall mounted Comms cabinets.
- Compact Footprint
- User-Replaceable Batteries
- Silent Operation - No Fans
- Compatible with all wall-mounted racks
- Extra IEC and Australian Outlets
- All Metal Enclosure
- 2RU Size
Specifications
Capacity
800VA / 480W
Topology
Line Interactive
Input
Voltage
240Vac (Nominal)
Voltage Range
177-290Vac
Frequency Range
50/60Hz (auto sensing)
Output
Output Voltage
240Vac ± 10%
Frequency Range (Batt. Mode)
50Hz/60Hz ±1Hz
Transfer Time
6ms (Typical)
Waveform (Batt. Mode)
Simulated Sine Wave
Australian Outlets - UPS & Surge Protection
2x 10A IEC Sockets, 6 x Australian Sockets
Battery
Battery Type & Number
12V / 9AH (x1)
Typical Recharge Time
4~6 hours recover to 90% capacity
Backup Time (50% Load)
8 min
Protection
Full Protection
Overload, discharge and overcharge protection
Surge Protection
312Joules / 6500Amps
Communication & Management
Interface
USB interface
Software
NetGuard® supports - Windows®, Linux, Unix and Mac (Free Download)
LCD Alarm
AC Mode, Battery Mode, Low Battery (Batt. Mode), Fault, Overload
Audible Alarm
Battery Mode, Low Battery (Batt. Mode), Fault, Overload
Physical
Dimension L x W x H
230 x 438 x 86mm (2RU)
Net Weight
7.7kg
Operating enviroment
Temperature
0°C~40°C
Humidity
0%-90% RH (non-condensing)
Noise Level
Less than 5dBA @ 1meter (no fan)
Safety/EMC
EN62040-1 -1 2003, IEC60950-1 : 2001, EN62040-2 2006
RoHS
Directive 2011/65/EU
