PowerShield Automatic Transfer Switch. Dual 16A IEC Input, 8 x 10A IEC,1 x 16A Output,19 1RU RackMountable, 9ms Typical Transfer Time. Includes USB, RS2332, AS400 Ports, Optional SNMP (PSSNMP)
PowerShield Automatic Transfer Switch. Dual 16A IEC Input, 8 x 10A IEC,1 x 16A Output,19 1RU RackMountable, 9ms Typical Transfer Time. Includes USB, RS2332, AS400 Ports, Optional SNMP (PSSNMP)
- Brand: PowerShield
- MPN: PSATS3K
- Part #: UPSPSD3006
- UPC:
View all shipping info
- Brand: PowerShield
- MPN: PSATS3K
- Part #: UPSPSD3006
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Other UPS Accessories





PowerShield Automatic Transfer Switch. Dual 16A IEC Input, 8 x 10A IEC,1 x 16A Output,19 1RU RackMountable, 9ms Typical Transfer Time. Includes USB, RS2332, AS400 Ports, Optional SNMP (PSSNMP)
- Brand: PowerShield
- MPN: PSATS3K
- Part #: UPSPSD3006

Product URL: https://www.pbtech.com/au/product/UPSPSD3006/PowerShield-Automatic-Transfer-Switch-Dual-16A-IEC
Features
POWERSHIELD Automatic Transfer Switch. Dual 16A IEC Input, 8 x 10A IEC,1 x 16A Output,19" 1RU Rack Mountable
The PowerShield Automatic Transfer Switch (ATS) is designed with two independent power inlets to supply power to the load from a primary or secondary power source. Should the primary power source fail, the secondary will automatically supply power to the connected equipment. The transfer time from one power source to the other is seamless to the connected equipment. PowerShield ATSAfter switching to a secondary power source, the ATS can also switch the power back to the primary input when power to the primary input is restored.
- Critical load (server) has the reliability of two independent power sources.
- Ideal for ensuring reliable power to critical devices that have only a single power - supply
- User-selectable power source from the front panel.
- Dual power supply for redundancy.
- Provides seamless power switch for IT equipment.
- Highly reliable 19? (1RU) rack design to fit into the diverse working environment.
- Built-in USB and RS232.
- AS400 dry contacts included.
- SNMP remote monitoring option available.
System Configuration
Specifications
Model Number
PSATS3K
INPUT
Input Voltage
220/230/240Vac
Acceptable Input Voltage
180 - 270Vac (selectable ranges)
Input Frequency
50Hz / 60Hz
Maximum Input Current
16A
OUTPUT
Output Voltage
220/230/240Vac
Transfer time
9 ms (typical)
CONNECTION
Input
2 x 16A (C20)
Output
8 x 10A (C13), 1 x 16A (C19)
Communication Included
USB, RS232 and AS400
Communication Optional
SNMP card
PHYSICAL
Dimensions (D x W x H)
330 x 483 x 44mm
Net Weight
5kgs
