Advantech AI Platform Based on NVIDIA Jetson MIC-713-OX3A1 Orin NX 8GB w/128GB SSD

PB Tech price
PB Tech price
$ 2,932 .28
 +GST
$ 3,225 .51
 inc GST
$2,932.28  +GST
$3,225.51

Advantech AI Platform Based on NVIDIA Jetson MIC-713-OX3A1 Orin NX 8GB w/128GB SSD

  • Brand: Advantech
  • MPN: MIC-713-OX3A1
  • Part #: IPCAVH080015
  • UPC:
PB Tech price
$ 2,932 .28 $ 3,225 .51
 +GST  inc GST


Delivery: Order now and it ships on 25 Sep
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$2,932.28  +GST
$3,225.51

Features

Advantech AI Platform Based on NVIDIA Jetson MIC-713-OX3A1 Orin NX 8GB w/128GB SSD 2 x GbE, 6 x USB3.2 Gen2, 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280, with 100-240V 230W 24V adaptor & MIC-733 PoE Board

- Compact fanless design
- Embedded NVIDIA® Jetson Orin™ NX up to 100 TOPS
- Supports 2 x GbE, 6 x USB 3.2 Gen 2
- Supports 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
- Supports Allxon 24/7 remote monitoring and OTA deployment

Specifications

Processor System

CPU

8GB: 6-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU

GPU

1024-core NVIDIA Ampere GPU with 32 Tensor Cores

Memory

8GB: 8GB LPDDR5

Flash

-

I/O

Ethernet

2 x 10/100/1000 Mbps

Display

HDMI (Max. resolution 3840x2160 @ 60Hz)

USB

External: 6 x USB 3.2 Gen 2

Digital I/O

4-ch DI, 4-ch DO

Serial Port (Optional)

2 x RS-232/422/485 (On-board pin header reserved)

CANBus

1

OTG USB

1 x Micro USB

Expansion

Mini PCIe

1 x mPCIe (Signal: PCIe + USB 2.0)

M.2

1 x M.2 3052 (Signal: USB)

SIM

2 x Nano SIM slots

TPM (Optional)

1 x TPM 2.0

GMSL (Optional)

2-ch GMSL2.0 with FAKRA connectors

Storage

M.2

1 x M.2 2280 (Signal: PCIe x1, Gen 4)

SD Card

1 x Micro SD

Power

Mode

AT

Input Voltage

9 ~ 36 VDC

Environment

Operating Temperature*

-10 ~ 50 °C with 0.7 m/s airflow

Operating Humidity

95% @ 40 °C (non-condensing)

Vibration

3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis

Shock

10G / 11ms

Mechanical

Dimensions (W x D x H)

194.8 x 174.3 x 65.85 mm (7.67" x 6.86" x 2.59")

Weight

2.05 kg (w/o packing material)

Installation

Desktop

BSP

Jetpack

Above 5.1

Manufacturer Part No:
MIC-713-OX3A1
Brand:
Product Type:
-
UPC
-
Product Family:
AI Platform Based on NVIDIA Jetson
Shipping Weight:
1 kg
PB Part No:
IPCAVH080015
Product Model:
MIC-713-OX3A1
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
