Advantech FPM-724W-P9AE 23.8" Full HD Industrial Monitor with P-CAP Touch Control, Direct HDMI, DP, and VGA Ports
- Brand: Advantech
- MPN: FPM-724W-P9AE
- Part #: IPCAVH221479

Product URL: https://www.pbtech.com/au/product/IPCAVH221479/Advantech-FPM-724W-P9AE-238-Full-HD-Industrial-Mon
Features
- 23.8" Full HD TFT LED LCD with true-flat touchscreen
- 16:9 wide screen aspect ratio, increases viewing area by 40%
- Supports 10-point multi-touch control via USB interface in Windows 7/8/10 OS
- Slim design enables easy installation
- Supports various mount options: panel, desktop, and VESA arm
- Touchscreen with reliable glass surface and P-CAP touch control
- Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
- Lockable I/O connectors
- Supports various mount options: panel, wall, desktop, rack or VESA arm mounting
Specifications
General
Certification
BSMI, CCC, CE, FCC Class A, UL, CB
Dimensions (W x H x D)
FPM-724W: 595.9 x 374.1 x 53 mm
(23.4" x 13.7" x 2.08")
Enclosure
Front panel: Die-casting aluminium,
Rear cover: Die-casting aluminium
Mount
Options Stand, Wall, Panel and VESA arm (75 x 75mm)
Power Input
Terminal Block: 24 VDC input
Video Port
HDMI, DP, and VGA
USB
Rear I/O USB 2.0 type A
Weight (Net)
4kg (8.82 lb) / 7kg (15.43 lb)/ 7.8kg (17.20 lb)
LCD Display
Display Type
Full HD TFT LED LCD
Display Size
23.8"
Max. Resolution
1920 x 1080
Max. Color
16.7M
Viewing Angle (H/V)°
178/178
Luminance (cd/m2)
350
Backlight Life (hrs)
30,000
Contrast Ratio
1000:1
Touchscreen
Type
Projected capacitive touch
Interface
USB
OS Support
Windows® 7, 8, 10, XPe, CE and Linux
Hardness
7H
Multi Touch
10 points, USB interface in Win 7/8/10, Linux
Touch Surface
Anti Glare (FPM-721W/FPM-724W)
Environment
Operating Temperature
-20 ~ 60 °C (-4 ~ 140 °F)
0 ~ 50 °C (32 ~ 122 °F) (FPM-724W only)
Storage Temperature
-30 ~ 70 °C (-22 ~ 158 °F)
Relative Humidity
Operating, 95% RH @ 40 °C, Non-Condensing
Non-Operating, Operating, 95% RH @ 60 °C,
Non-Condensing
Waterproof
Front Panel IP66 Compliant
Vibration
5 ~ 500 Hz, 1 Grms (Operating, Random)
Power Consumption
FPM-724W-P9AE
0.161 (Standby), 24.41 (Max)
Ordering Information
FPM-724W-P9AE
23.8" Full HD Ind. Monitor, w/ PCAP touch
Optional Accessories
PWR-247-DE
Adapter 100-240V 60W 24V 2.5A
FPM-1000T-SMKE
Desktop/Wall Mounting kit for FPM series
FPM-7000G-ADKE
Mounting bracket of adapter for FPM-7000
