Advantech TPC-B300-J20A Modular TPC - Computing Box Module with Intel Celeron J6412

PB Tech price
PB Tech price
$ 903 .92
 +GST
$ 994 .31
 inc GST
$903.92  +GST
$994.31

Advantech TPC-B300-J20A Modular TPC - Computing Box Module with Intel Celeron J6412

  • Brand: Advantech
  • MPN: TPC-B300-J20A
  • Part #: IPCAVH500012
  • UPC:
PB Tech price
$ 903 .92 $ 994 .31
 +GST  inc GST


Delivery: Order now and it ships on 30 Jun
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$903.92  +GST
$994.31

Features

Advantech TPC-B300 Modular TPC - Computing Box Module with Intel Atom and Celeron CPU

- Computing Box powered by Intel Atom® X6425E/ Intel® Celeron® J6412 with DDR4 SODIMM slot (up to 32GB)
- Multiple sized front panel module offering with P-Cap multi-touch sensor (12.1" & 19" w/ robust 5-wire resistive touch)
- 1 x Full-size mini PCIe for iDoor expansion
- 1 x M.2 Key-E 2230 for WIFI + BT module
- 1 x M.2 Key-M 2280 for SATA SSD
- 1 x 2.5" SATA SSD expansion
- 2 x 2.5Gb LAN
- Supports TPM2.0 hardware security
- Wide Temp Support. Range -20~60 °C (Atom™ X6425E)

Flexible Performance and Memory Options

The Advantech TPC-B300 Modular Computing Box packs a strong computing punch by offering options powered with either the Intel Atom® X6425E or the Intel® Celeron® J6412 processor. Accompanied by a DDR4 SODIMM slot supporting up to 32GB RAM, this system is ready to tackle a broad array of industrial and commercial applications requiring reliable and robust processing.

Versatile Front Panel and Touch Solutions

Designed for adaptability, the TPC-B300 comes with multiple front panel module options. Users can choose between 12.1-inch or 19-inch displays, both equipped with P-Cap (Projected Capacitive) multi-touch sensors for intuitive interactions. Additionally, the panels support a rugged 5-wire resistive touch alternative, allowing for reliable operation even in demanding environments.

Expansion Capabilities and Connectivity

This modular computing box is built for expandability. It features a full-size mini PCIe slot compatible with Advantech's iDoor expansion modules, enabling tailored I/O, fieldbus, or communication functions. Furthermore, an M.2 Key-E 2230 slot allows for Wi-Fi and Bluetooth connectivity, while an M.2 Key-M 2280 and a 2.5" SATA slot provide flexible SSD storage options.

Advanced Networking and Security

Networking is robust on the TPC-B300 thanks to dual 2.5Gb LAN ports, ensuring high-speed connection and redundancy for industrial networks. Security is also a priority, as TPM 2.0 hardware support is integrated, providing trustworthy hardware-level protection for sensitive data and system authentication.

Wide Temperature Range and Rugged Durability

Ideal for industrial settings, the Advantech TPC-B300 supports a wide operating temperature range from -20°C to 60°C (for Atom™ X6425E models). This ensures stable and reliable performance in a variety of challenging environmental conditions, making it suitable for factories, automation control, and outdoor applications.

Specifications

Environment

Operating Temperature

-20~55 °C (-4~131 °F)

Storage Temperature

-20~70 °C (-4~158 °F)

Vibration Protection

1 Grms

Hardware

Certification

CB, UL, CE, FCC Class A, CCC, BSMI

CPU

Intel® Celeron® J6412 2.00 GHz, Quad core

Expansion

1 x Full-size mPCIe slot

Hardware Security

TPM 2.0

I/O

1 x RS-232, 1 x RS-232/422/485

LAN

2 x 10/100/1000/2500 Mbps

Memory

1 x DDR4 SO-DIMM Slot

OS Support

Microsoft® Windows 10 LTSC, Microsoft® Windows 10 LTSB, Linux, Android

Power Input

24 VDC ±20%

Storage

1 x SATA M.2 SSD slot (2280 M-Key), 1 x 2.5" SSD/HDD Bay

I/O Interface

USB Ports

3 x USB 3.2, 1 x USB 2.0

Mechanical

Dimension (W x H x D)

269 x 203 x 30 mm

Mounting

Panel, Wall, Stand, VESA

Weight (Net)

2 kg (4.41 lb)

Manufacturer Part No:
TPC-B300-J20A
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCAVH500012
Product Model:
TPC-B300-J20A
Warranty: 12 months *
