LENKENG LKV565P HDMI 2.0 Extender over Cat6/6e with PoE for Rx. Supports up to4K60Hz.ZeroLatency. One Way IR Remote Control. Transmit HDMI Signal up to 70m. EDID Passback. L/R Audio Output Rx

PB Tech price
PB Tech price
$ 143 .00
 +GST
$ 157 .30
 inc GST
$143.00  +GST
$157.30

LENKENG LKV565P HDMI 2.0 Extender over Cat6/6e with PoE for Rx. Supports up to4K60Hz.ZeroLatency. One Way IR Remote Control. Transmit HDMI Signal up to 70m. EDID Passback. L/R Audio Output Rx

  • Brand: LENKENG
  • MPN: LKV565P
  • Part #: KVMLNK1163
  • UPC:
1
PB Tech price
$ 143 .00 $ 157 .30
 +GST  inc GST


Delivery: Order now and it ships today
Express Delivery Times
Metro - Within 2-3 working days
Rural - Within 3-5 working days

Standard Delivery Times
NSW, VIC, ACT, QLD - Within 3-7 working days
SA, WA, TAS, NT - Within 5-10 working days

View all shipping info
$143.00  +GST
$157.30
  • Brand: LENKENG
  • MPN: LKV565P
  • Part #: KVMLNK1163
  • UPC:

What PB Tech customers are saying about this product...

See More Reviews

"Using an Integra DRX-4 Receiver with a Panasonic TH-58EX780Z TV. Connected the two over a Cat 6a run. Device works as expected driving a 4K, 50hz picture to the TV.

Not using soun ...view more"

CB
By: ColinB54 18/02/25
Verified Owner

Features

This is an HDMI point-to-point extender kit, it can realize zero-latency transmission. The 4K@60Hz HDMI signal can be extended by 70m through CAT6/6A/7 network cable. It supports HDMI loop out, IR passthrough, 3.5mm audio output, etc. This kit is a reliable, ultra-high-definition video transmission solution, which is widely used in security monitoring, home theater, broadcasting, training and other fields.

Zero Latency Transmission for 70 Meters

Support CAT6/6A/7 network cable, the maximum transmission distance can reach 70 meters

4k A 60Hz HDR for Visually Lossless Transmission

Support 3840x2160 HDR, with ipcolor IMAGE - a new standard for visually lossless transmission solution, the image can be more clear, higher saturation and show more outstanding details.

Support PoC-Power over Network Cable

Only TX Power Supply Needed.

Specifications

HDMI Length

=5m

Maximum transfer rate

18Gbps

Maximum transmission bandwidth

600MHz

EDID passthrough

Yes

Compatibility

HDMI 2.0(Deep color, 4K, HDR, YUV4:4:4)
HDCP 2.2

Resolutions

720p @ 50/60Hz?1080i @ 50/60Hz?1080p @ 50/60Hz? 3840x2160 @ 24/25/30/50/60Hz?4096x2160 @ 24/25Hz? 1280x960?1280x800?1280x768?1680x1050? 1360x768?1366x768?1600x900?1024x768?800x600

Transmission distance

CAT6/6A/7=70m

Audio formats

LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos

IR interface

TX:1x 3.5mm IR OUT Female
RX:1x 3.5mm IR IN Female

Receiving range=

=5m

Infrared frequency

20KHz~60KHz

Power Supply

TX:DC5V/2A
RX:DC5V/2A

Power Consumption

TX:<4W
RX:<4W

Working temperature

-20?~60?

Storage temperature

-30?~70?

Humidity

0~90%RH(No condensation)

Housing

Metal

Weight

TX:140g
RX:140g

Color

Black

Dimensions

TX/RX:85.0(L)*75.5(W)*16.5(H)mm

Manufacturer Part No:
LKV565P
Brand:
LENKENG
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.65 kg
PB Part No:
KVMLNK1163
Product Model:
-
Warranty: 24 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

5 out of 5 Stars Based on 1 review
5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Stars
0

Do you own this product?

Write a review and go into the monthly draw Win A $100 PB Tech Gift Card!

Connect TV and Receiver at a distance.

Using an Integra DRX-4 Receiver with a Panasonic TH-58EX780Z TV. Connected the two over a Cat 6a run. Device works as expected driving a 4K, 50hz picture to the TV.

Not using sound sourced from the TV so can’t confirm if ARC works. Nothing in the manual suggests it will work.

CB
By: ColinB54 18/02/25
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?
