MikroTik CRS320-8P-8B-4S+RM 16 Port Gigabit PoE Switch (8x 802.3af/at and 8x802.3af/at/bt compliant) with 4 SFP+ Fiber Uplink Ports
MikroTik CRS320-8P-8B-4S+RM 16 Port Gigabit PoE Switch (8x 802.3af/at and 8x802.3af/at/bt compliant) with 4 SFP+ Fiber Uplink Ports
- Brand: MikroTik
- MPN: CRS320-8P-8B-4S+RM
- Part #: NETMKT1476
- UPC:
View all shipping info
- Brand: MikroTik
- MPN: CRS320-8P-8B-4S+RM
- Part #: NETMKT1476
- UPC:
Features
MikroTik CRS320-8P-8B-4S+RM 16 Port Gigabit 802.3af/at/bt PoE Switch with 4 SFP+ Uplinks.
The first MikroTik high-power PoE++ switch - for easy and cost-effective powering of industry standard 802.3af/at/bt devices. Forget about countless power cables - create a cleaner space with PoE++!
The MikroTik CRS320-8P-8B-4S+RM Cable management can get really exhausting. But it doesn't have to. MikroTik's first PoE++ or 802.3bt switch can make your cable management so much easier, as it can output enough power for all your hotel, conference hall, office and high-rise building needs!
4K security cameras with built-in winter heating elements, LED ad screens, PoE-powered light fixtures - CRS320 can output up to 90W per port, enough even for the most demanding devices! It comes with a reliable 600 W power supply, but we've reserved an expansion slot for an additional PSU, in case you need to raise the power output to 1150 W.
There are 17 Gigabit Ethernet ports: #1 - #8 Gigabit Ethernet ports with 802.3af/at PoE-out, #9 - #16 802.3bt PoE++ ports, and an extra Gigabit Ethernet port for management purposes. There's also a console port, and four 10G SFP+ fiber ports for uplink.
At its core, this convenient switch has a phenomenal Marvel switch-chip - the same one you've seen in ISP bestsellers like the netPower 16P and netFiber 9! It can handle the heaviest loads, including VLAN-filtering and hardware-offloaded Layer-3 routing.
If you've been looking for a way to simplify your cable management - this is it! With a single CRS320, you can ditch that endless mess of DC power adapters and start living the clean minimalist PoE dream.
Unlike our previous 802.3af/at Power Sourcing Equipment, this is our first PoE switch with full implementation of the 802.3af/at/bt standard. It supports only fully compliant 802.3 at/af/bt Powered Devices - mAP-lite / RB1100AHx4 / CRS510-8XS-2XQ / CRS504-4XQ / FTC11XG / CRS305-1G-4S+OUT. While it can also power "802.3af/at/bt-compatible" Powered Devices, you must avoid specific grounding scenarios. Please refer to the Official Help Page (https://help.mikrotik.com/docs/spaces/UM/pages/250708058/CRS320-8P-8B-4S+RM)
One hot-swappable PSU is included.
- Max Power Output: 1150 W!
- 17x 1Gbps Ethernet Ports (Support 10M / 100M / 1G Speeds)
- 4x 10Gbps SFP+ Ports (Support 1G / 2.5G / 10G Speeds, depending on module)
- PoE+ (802.3af/at) on Ports #1-8 - Up to 30W per port
- PoE++ (802.3af/at/bt) on Ports #9-16 - Up to 90W per port
- PSU Expansion Slot
- Console Port
Specifications
Reviews
Delivery & Pick-up
.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security and Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
Delivery Estimates
The delivery time-frame (in days) for each product we sell is detailed on the individual product page just to the right of the main product image. From when you place your order, for DHL express delivery in-stock products typically arrive within 2-3 working days for metro areas and 3-5 working days for rural areas. For Standard delivery in-stock products typically arrive within 3-7 working days for NSW, VIC, ACT, QLD and SA deliveries and 5-10 working days for WA, TAS and NT.
Overseas Shipments
If you are located in New Zealand, you can order directly from our New Zealand site www.pbtech.co.nz. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Switches
Ubiquiti UniFi USW-Flex-Mini 5-Port Gigabit L2 Managed Switch -...
TP-Link TL-SG1005D 5-Port Gigabit Desktop Switch
TP-Link TL-SG105 5-Port 10/100/1000Mbps Desktop Switch
TP-Link TL-SG108PE 8-Port Gigabit Easy Smart PoE Switch with 4...
Ubiquiti UniFi USW-Lite-8-POE 8-Port Gigabit L2 Managed PoE...
MikroTik CRS320-8P-8B-4S+RM 16 Port Gigabit PoE Switch (8x 802.3af/at and 8x802.3af/at/bt compliant) with 4 SFP+ Fiber Uplink Ports
- Brand: MikroTik
- MPN: CRS320-8P-8B-4S+RM
- Part #: NETMKT1476
Product URL: https://www.pbtech.com/au/product/NETMKT1476/MikroTik-CRS320-8P-8B-4SRM-16-Port-Gigabit-PoE-Swi
Features
MikroTik CRS320-8P-8B-4S+RM 16 Port Gigabit 802.3af/at/bt PoE Switch with 4 SFP+ Uplinks.
The first MikroTik high-power PoE++ switch - for easy and cost-effective powering of industry standard 802.3af/at/bt devices. Forget about countless power cables - create a cleaner space with PoE++!
The MikroTik CRS320-8P-8B-4S+RM Cable management can get really exhausting. But it doesn't have to. MikroTik's first PoE++ or 802.3bt switch can make your cable management so much easier, as it can output enough power for all your hotel, conference hall, office and high-rise building needs!
4K security cameras with built-in winter heating elements, LED ad screens, PoE-powered light fixtures - CRS320 can output up to 90W per port, enough even for the most demanding devices! It comes with a reliable 600 W power supply, but we've reserved an expansion slot for an additional PSU, in case you need to raise the power output to 1150 W.
There are 17 Gigabit Ethernet ports: #1 - #8 Gigabit Ethernet ports with 802.3af/at PoE-out, #9 - #16 802.3bt PoE++ ports, and an extra Gigabit Ethernet port for management purposes. There's also a console port, and four 10G SFP+ fiber ports for uplink.
At its core, this convenient switch has a phenomenal Marvel switch-chip - the same one you've seen in ISP bestsellers like the netPower 16P and netFiber 9! It can handle the heaviest loads, including VLAN-filtering and hardware-offloaded Layer-3 routing.
If you've been looking for a way to simplify your cable management - this is it! With a single CRS320, you can ditch that endless mess of DC power adapters and start living the clean minimalist PoE dream.
Unlike our previous 802.3af/at Power Sourcing Equipment, this is our first PoE switch with full implementation of the 802.3af/at/bt standard. It supports only fully compliant 802.3 at/af/bt Powered Devices - mAP-lite / RB1100AHx4 / CRS510-8XS-2XQ / CRS504-4XQ / FTC11XG / CRS305-1G-4S+OUT. While it can also power "802.3af/at/bt-compatible" Powered Devices, you must avoid specific grounding scenarios. Please refer to the Official Help Page (https://help.mikrotik.com/docs/spaces/UM/pages/250708058/CRS320-8P-8B-4S+RM)
One hot-swappable PSU is included.
- Max Power Output: 1150 W!
- 17x 1Gbps Ethernet Ports (Support 10M / 100M / 1G Speeds)
- 4x 10Gbps SFP+ Ports (Support 1G / 2.5G / 10G Speeds, depending on module)
- PoE+ (802.3af/at) on Ports #1-8 - Up to 30W per port
- PoE++ (802.3af/at/bt) on Ports #9-16 - Up to 90W per port
- PSU Expansion Slot
- Console Port
Specifications
Brand
MikroTik
MPN
CRS320-8P-8B-4S+RM
CPU
Dual-Core 800 MHz
CPU architecture
ARM 32bit
Size of RAM
256 MB
RAM type
DDR3
Storage
32 MB, Flash
Number of 1G Ethernet ports
17 (Support 10M / 100M / 1G speeds)
Number of 10G SFP+ ports
4 (Support 1G / 2.5G / 10G speeds, depending on module)
Switch chip model
98DX226S
Operating system
RouterOS v7 only, License level 5
Dimensions
444 x 235 x 44 mm
Operating temperature
-10°C to +50°C
Number of AC inputs
1
Nominal current
10.35 A
Max current
11 A
AC input range
100-240 V
Frequency
50-60 Hz
Smart PoE
Controller
PoE-out ports
Ether1-Ether8 (af/at), Ether9-Ether16 (bt)
Max out per port output (input > 30 V)
560 (af/at) / 1667 (bt) mA
Max total out
17.82 A
Total output power
963 W
Total output current
17.82 A
Max power consumption (without attachments)
36 W
Max power consumption
600 W (1150 W with additional PSU)
